Surface Grinding Machine/Surface Grinder 7132

Name: Surface Grinding Machine/Surface Grinder 7132
Brand: China-Manufacturer-Directory.com
SKU: 724540355
Availability: InStock
Rating: 4.5 (56 reviews)

Supplier:	ACE Machine Tools Co., Ltd.
Price:	Negotiable/Piece
Min Order:	1/Piece
Quantity::
Trade Terms:	FOB,CFR,CIF

Product Specifications

Prod Model:	7132
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Size:	320*1000mm
Automatic Grade:	Automatic
Precision:	Precision
Type:	Surface Grinding Machine
Controlling Mode:	Artificial
Processing Object:	Curve

Product Description

Surface Grinding Machine/Surface grinder 7132

MAIN APPLICATION
Be applicable to working of various spare parts, such as machine processing, car accessories, work tongs and clamping tools, magnetic steel and molding tools...Etc. This machine can be used to grind various kinds of blankets of different materials such as steel, iron, porcelain and ceramics, non-ferrous metals and etc...

We provide high quality and best service.

Product Description
Main Specifications		Unit	SG7132×30A-GM	SG7132×40A-GM
Table	Table working surface (W×L)	mm	320×3000	320×4000
	Max. size of workpiece to be ground (W×L×H)	mm	320×4000×400	320×4000×400
	Table Longitudinal travel (Hydraulic)	mm	200-3100	200-4100
	Speed of table (Stepless)	m/min	3-25	3-25
	Table "T" slots	mm	3	3
	Width	mm	18	18
	Max. allowable weight of workpiece (Including electromagnetic chuck)	kg	1497	1996
	Electromagnetic chuck size (W×L)	mm	320×(1500×2)	320×(2000×2)
Grinding wheel head	Max. travel wheel-head	mm	430	430
	Cross (manual or power-operated)
	Vertical (manual or power-operated)		400	400
	Automatic cross-feed of wheel-head (Stepless)	mm	0.8-3.5	0.8-3.5
	Continuous
	Intermittent	mm	3-20/stroke of table	3-30/stroke of table
	Wheel-head feed for each turn of hand-wheel	mm	3	3
	Vertical	mm	0.175	0.5
	Min. Down-feed hand-wheel dial graduated to	mm	0.5	0.5
	Grinding wheel size (O.D×W×I.D)	mm	φ400×50×φ203	φ400×63×φ203
	Wheel-heed rapid up-down traverse speed	mm/min	310	310
Motor power	Hydraulic Pump Flow	L/min	100	159
	Electrical equipment total capacity	KVA	20	25
	Grinding wheel motor power	Kw	7.5	9
	Speed	r/min	1440	1440
	Hydraulic pump motor power	Kw	7.5	11
	Speed	r/min	1440	1460
	Wheel-head rapid elevation motor power	Kw	0.37	0.37
	Speed	r/min	1400	1400
	Delivery	L/min	100	100
	Coolant pump motor power	kVA	0.25	0.25
	Speed	r/min	3000	3000
work accuracy	Working surface to base level parallelism	mm	300:0.008	300:0.008
work accuracy	Surface roughness	μm	Ra0.63	Ra0.63
Base parameter	Overall dimensions (L×W×H)	mm	8350×1786×2280	10310×1786×2280
	Packing case dimensions (L×W×H)	cm	685×206×285	885×210×285
	Weight of machine	kg	11000	13000

ACE MACHINE TOOLS Co., Ltd, is a specialized exporter and manufacturer of machine tools and accessories with a long history.

Our mechanical products cover more than 80 kinds including lathe, milling machine, drilling machine, grinding machine, power press, hydraulic guillotine, hydraulic press brake, CNC & automotive machines and so on.

Our customers are widespread in more than 30 countries including U. S. A., Germany, Spain, France, England, Greece, Finland, Norway, Canada, south America, Middle East, Australia, Africa and southeast Asia etc.

Our principle to all the customers is high quality and good service. We have quality control team who will carefully inspect every machine in workshop before packing.

Welcome you to visit our website and contact us. We will give you quick response upon any of your need.
