Surface Grinding Machine/Surface Grinder M7160

Name: Surface Grinding Machine/Surface Grinder M7160
Brand: China-Manufacturer-Directory.com
SKU: 724540405
Availability: InStock
Rating: 4.6 (125 reviews)

Supplier:	ACE Machine Tools Co., Ltd.
Price:	Negotiable/Piece
Min Order:	1/Piece
Quantity::
Trade Terms:	FOB,CIF

Product Specifications

Prod Model:	M7160
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Automatic Grade:	Automatic
Precision:	Precision
Type:	Surface Grinding Machine
Controlling Mode:	Artificial
Processing Object:	Curve

Product Description

Surface Grinding Machine/Surface grinder M7160

This series of surface grinder is most suitable for the grinding steel, casting and non-ferrous parts of machine manufacturing industry.

The longitudinal movement of the worktable is driven by vane pump, which makes the movement smooth and low noise.

The machine moves smoothly and has reliable performance, low noise and stable accuracy. It is easy to operate and deeply welcomed by the customers.

Product Description
Main Specifications		Unit	SG7140/CK	SG7140/CK-GM	SG7160/CK-GM	SG7163/CK-GM
Table	Table working surface (W×L)	mm	400×1000	400×1000	600×1000	630×1250
	Max. size of workpiece to be ground (W×L×H)	mm	400×1000×400	400×1000×400	600×1000×400	630×1250×400
	Table Longitudinal travel (Hydraulic)	mm	200-1100	200-1100	200-1100	200-1350
	Speed of table (Stepless)	M/min	3-25	3-25	3-25	3-25
	Table "T" slots	mm	3	3	3	3
	Width	mm	18	18	22	22
	Max. allowable weight of workpiece (Including electromagnetic chuck)	kg	624	624	980	980
	Electromagnetic chuck size (W×L)	mm	400×1000	400×1000	600×1000	630×1250
Grinding wheel head	Automatic cross-feed of wheel-head (Stepless)	M/min	0.8-3.5	0.5-3	0.5-2.5	0.5-2.5
	Continuous
	Intermittent	mm/m	3-30	3-30	3-30	3-30
	Max. Travel of wheel-head cross (manual or hydraulic)	mm	430	450	650	680
	Wheel-head feed for each turn of hand-wheel	mm	0.5	0.5	0.5	0.5
	Vertical	mm	0.5	0.5	0.5	0.5
	Grinding wheel size (O.D×W×I.D)	mm	φ400×50×φ203	φ350×40×φ127	φ400×50×φ203	φ400×50×φ203
Motor power	Electrical equipment total capacity	KVA	12	14	14	14
	Grinding wheel motor power	KW	7.5	7.5	7.5	7.5
	Speed	r/min	1440	1440	1440	1440
work accuracy	Working surface to base level parallelism	mm	300:0.005	300:0.005	300:0.008	300:0.008
work accuracy	Surface roughness	μm	Ra0.63	Ra0.63	Ra0.63	Ra0.63
Base parameter	Overall dimensions (L×W×H)	mm	3000×1736×2280	3000×1782×2057	3040×2073×2280	3540×2073×2280
	Packing case dimensions (L×W×H)	cm	360×191×258	304×190×230	343×218×270	383×233×262
	N.W	kg	4500	3900	4800	5100

ACE MACHINE TOOLS Co., Ltd, is a specialized exporter and manufacturer of machine tools and accessories with a long history.

Our mechanical products cover more than 80 kinds including lathe, milling machine, drilling machine, grinding machine, power press, hydraulic guillotine, hydraulic press brake, CNC & automotive machines and so on.

Our customers are widespread in more than 30 countries including U. S. A., Germany, Spain, France, England, Greece, Finland, Norway, Canada, south America, Middle East, Australia, Africa and southeast Asia etc.

Our principle to all the customers is high quality and good service. We have quality control team who will carefully inspect every machine in workshop before packing.

Welcome you to visit our website and contact us. We will give you quick response upon any of your need.
