Surface Grinding Machine/Surface Grinder (SG7130)

Name: Surface Grinding Machine/Surface Grinder (SG7130)
Brand: china-manufacturer-directory.com
SKU: 724540325
Availability: InStock
Rating: 4.8 (122 reviews)

Supplier:	ACE Machine Tools Co., Ltd.
Price:	Negotiable/Piece
Min Order:	1/Piece
Quantity::
Trade Terms:	FOB,CIF

Product Specifications

Prod Model:	SG7130
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Worktable Size:	320*1000mm
Automatic Grade:	Automatic
Precision:	Precision
Type:	Surface Grinding Machine
Controlling Mode:	Artificial
Processing Object:	Curve

Product Description

Surface Grinding Machine/Surface grinder (SG7130)

This series of surface grinder is most suitable for the grinding steel, casting and non-ferrous parts of machine manufacturing industry.

The longitudinal movement of the worktable is driven by vane pump, which makes the movement smooth and low noise.

The machine moves smoothly and has reliable performance, low noise and stable accuracy. It is easy to operate and deeply welcomed by the customers.

Product Description
Main Specifications		Unit	SG7130G/F	SG7132-GM
Table	Table working surface (W×L)	mm	320×1000	320×1000
	Max. size of workpiece to be ground (W×L×H)	Mm	320×1000×400	320×1000×400
	Table Longitudinal travel (Hydraulic)	mm	200-1110	200-1110
	Speed of table (Stepless)	m/min	3-25	3-25
	Table "T" slots	mm	3	3
	Width	mm	18	18
	Max. allowable weight of workpiece (Including electromagnetic chuck)	Kg	500	500
	Electromagnetic chuck size (W×L)	mm	300×680	300×680
Grinding wheel head	Max. Travel of wheel-head cross	mm	380	380
	Automatic cross-feed of wheel-head (Stepless)	m/min	0.8-3	0.8-3
	Continuous
	Intermittent	mm	3-30/stroke of table	3-30/stroke of table
	Wheel-head feed for each turn of hand-wheel	mm	0.5	0.5
	Vertical	mm	0.5	0.5
	Min. Down-feed hand-wheel dial graduated to	mm	0.01	0.01
	Grinding wheel size (O.D×W×I.D)	mm	φ350×40×φ127	φ350×40×φ127
Motor power	Electrical equipment total capacity	KVA	14	14
	Grinding wheel motor power	KW	7.5	7.5
	Speed	r/min	1440	1440
work accuracy	pcsWorking surface to base level parallelism	mm	300:0.008	300:0.008
work accuracy	Surface roughness	μm	Ra0.63	Ra0.63
Base parameter	Overall dimensions (L×W×H)	Mm	3000×1712×2057	3000×1712×2057
	Packing case dimensions (L×W×H)	Cm	261×167×242	261×167×242
	N.W	kg	3200	3200

ACE MACHINE TOOLS Co., Ltd, is a specialized exporter and manufacturer of machine tools and accessories with a long history.

Our mechanical products cover more than 80 kinds including lathe, milling machine, drilling machine, grinding machine, power press, hydraulic guillotine, hydraulic press brake, CNC & automotive machines and so on.

Our customers are widespread in more than 30 countries including U. S. A., Germany, Spain, France, England, Greece, Finland, Norway, Canada, south America, Middle East, Australia, Africa and southeast Asia etc.

Our principle to all the customers is high quality and good service. We have quality control team who will carefully inspect every machine in workshop before packing.

Welcome you to visit our website and contact us. We will give you quick response upon any of your need.
