Product Specifications
| Prod Model: |
QFJ-1300D |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Inverter: |
Inovance |
| Main Driver: |
Yaskawa |
| Tension: |
Taiwan |
| Dance Roll Treatment: |
Taiwan 6 Degree |
| Loading: |
Shaftless Hydraulic |
| Suitable Material: |
Jumbo Roll to Small Roll |
| Automatic Tension Control: |
Yes |
| Industrial Usage: |
Package Cigar |
| Type: |
High-Speed Slitting Machine |
| Work Method: |
Round Knife Cutting |
Product Description
Max. Parent Web Width
800mm
Max. Parent Web Diameter
1500mm
Max. Rewinding Diameter
400mm (220M/MIN FOR OPTION)
Min. Slitting Width
Round Cutters: 20mm
Razor Cutters: 5mm
Thickness Range
Paper : 20-200gsm
Plastic: 0.02-1.2mm
Max. Slitting Speed
400m/min
Unwinding/Rewinding Shaft
3" Pneumatic Air Expanding Shaft
Voltage
Three-phase,Four-wire,380V, 50HZ
Overall Dimension(LxWxH)
3500*2000*3000mm
Weight
3500kgs
Specifications:
Application Material: Cigarette Paper, Tipping Paper, Regular Paper,Kraft Paper, Non-woven Cloth, Film, Bond Paper,
Aluminum Foil,plastic film,etc.
1).It adopts Panasonic PLC and touch screen, all the parameter are displayed on the monitor. You only need to setup
the material roll diameter and thickness, the PLC will give a proper parameters for machine running automatically.
2).400m/min High Speed Plastic Slitting machine adopts three sets of Inovance Inverters, to make the machine running stable.
3).It adopts Pneumatic system for the pressure roller control, the pressure is adjustable.
4).400m/min High Speed Plastic Slitting machine adopts rubber roller space for the lower cutter, which is used to support
slitting paper avoid any paper folding.
5).It adopts two Pedal Control Emergency Switches, which are used for on-off control.
6).It adopts photocell tracking system to provide accurate slitting position. Taiwan
7).It adopts automatic tension controller(diameter-calculating type) to gain a constant tension.
8).It adopts automatic meter counter which will stop the machine when reach the pre-set length.
