(SVM-2010) Digital Measuring Microscope
| Price: |
Negotiable/Piece |
| Trade Terms: |
FOB,CFR,CIF |
| Min Order: |
1/Piece |
| Pay Type: |
T/T |
Product Specifications
| Prod Model: |
SVM-2010 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| X,Y,Z-Axis Accuracy: |
±(3+L/200)Um |
| Metal Stage Size: |
408 X 280mm |
| Glass Stage Size: |
306 X 196mm |
| X,Y-Axis Travel: |
200 X196mm |
| Z-Axis Travel: |
150mm |
| Dimension(Dxwxh): |
530X540X850mm |
| Net Weight: |
110kg |
| Magnification: |
>1000X |
| Type: |
Video |
| Number Of Cylinder: |
Binoculars |
| Mobility: |
Desktop |
| Shape: |
Cylindrical Shaped Lens |
| Principle: |
Optics |
Product Description
Characteristic:
Video displaying and 30°. eyepiece observing;
Zoom objective maginification 1.0X-6.5X;.
Contour surface and LED coaxial illrmination three types illumination adjustable;
High resolution in focus all the zoom couse;
0.5X CCD adapter 0.5X,2X and 5X APO auxilary objective available;
Multifunction data processing system DRO DP600 and Quickmeasuring 2.0 Software Available;
Excel, Word and TXT Multi-formart report output, and DXF input and output;
Non-contact optical height measurement.
Specification:
| Model | SVM-2010 | SVM-2515 | SVM-3020 |
| Code# | 532-112 | 532-122 | 532-132 |
| Metal Stage Size | 408 x 280mm | 458 x 358mm | 558 x 458mm |
| Glass Stage Size | 306 x 196mm | 350 x 280mm | 450 x 350mm |
| X,Y-axis Travel | 200 x196mm | 250 x150mm | 300 x 200mm |
| Z-axis Travel | 150mm |
| X,Y,Z-axis Accuracy | ±(3+L/200)um |
| Linear Scale | High-precision Linear Scale, Resolution:0.0005 |
| Dimension(L x W x H) | 530x540x850mm |
| Microscope head | Eyepiece:High-eye-point and wide-field Eyepiece SWF10/23 |
| Objectives:Zoom Stereo Objectives:1.5x~10x |
| Optical Magnification:63.5x-423x(Extend to 32x-2115x) |
| Trinocular microscope head, Inclined at 30°, |
| Interpupillary Distance: 55~75mm |
| Illuminators | Contour | Adjustable 256-frade LED Illumination |
| Surface |
| Coaxial | Adjustable LED Coaxial Illumination |
| Digital Magnification System | 1/3''Color CCD Camera ,1x CCD adapter |
| Digital magnification:30x~230x(it can extend to 15x-1150x) |
| Digital Measuring System | HP/DELL PC System with 17'' quadrate monitor |
| Digital readout DP 600 |
| QuickMeasuring 2.0 |
| Dimension(DxWxH) | 530x540x850mm |
| Net Weight | 110kg |
