Product Specifications
| Prod Model: |
CNC-1500 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| CNC-1500: |
Table Plasma Cutting Machine |
| Application: |
Machinery & Hardware |
| Automation: |
Semi-automatic |
| Type For Cutting Machine: |
Plasma Cutting Machine |
| Type: |
Plasma Cutting |
Product Description
It is especially applicable to the cutting of small-size middle thin plate with high precision;
It is compatible with the PC machine of gantry type digital control cutter;
It can be used to cut any plan geometric figure;
According to the needs of users, it can be designed to be smoke evacuation type worktable or underwater cutting type workable to realize "environment friendly" cutting.
The machine body and the material support are integrated as a whole. They may be moved integrally. It is an economic, applicable, high efficient, high precision, high speed plasma cutting type.
Technical parameters:
Machine Shelf
Effective Cutting Width: 1500mm
Effective Cutting Length: 3000mm
Driving way: Double Driven (Two Motors)
Driving Speed: 0~12000mm/min
Plasma Cutting
Plasma Torch: 1 piece
Plasma Torch Height Regulator: USA Hypertherm Command THC (1 set)
Plasma Power: USA Thermadyne CUTMASTER A120
Plasma Cutting Thickness: Max pierce cutting thickness: 16mm, Max quality cutting thickness: 16mm, Max edge cutting thickness: 35mm.
Software: Nesting Software: InteGNPS of China
System: CNC System: Adtech HC6500
Features of system:
ARM9 industrial processor high cost performance embedded system
Won't be infected by Windows virus
Highly stable hardware structure
Ultra low power consumption, preventing system halted under high temperature
Switch on/off at will
Support all processing documents that managed by file.
Each program can save up to 50, 000 lines of processing codes
System documents have save and restore function
Help function, user-friendly, simple, easy to operate
Can be linked with a standard PS keyboard outside
10.4" color LCD display
Travel Reducer: Japan SHIMPO Reducer
Power: Machine body: Single phase 220V, 50/60Hz
Plasma power supply: Three phase 380V, 50/60Hz (It can be made according to your requirements. )
Spare Parts: Plasma cutting nozzles
Power supply cable
Plasma source cable and ground circuit
Fuse and hose
Electric and machinery drawings and all the manuals.
