Product Specifications
| Prod Model: |
DLPLC-1200GD |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Structure: |
Portable Type |
| PLC: |
Panasonic or Other |
| Input Power: |
Single Phase 110V ± 10% 50/60Hz; |
| Dimension: |
1800×800×1662mm |
| Installed Capacity: |
<250va; |
| Type: |
Teaching Model |
| Laser Model: |
Advanced Electrical Maintancetechnology Training |
| Usage: |
Training |
Product Description
DLPLC-1200GD
Programmable Logic Controller Training Set
1. Overview
DLPLC-1200GD programmable logic controller comprehensive training set is innovative practice training platform which composed of experiment table, power box, PLC hanging box (Siemens S7-1200GD), and various simulation hanging box and module.
Integrated the PLC principle and application technology (Siemens S7-1200GD) configuration king software application technology. This can be done PLC-related projects and assessment of various experiments through the platform, students quickly master PLC works and programming methods in the experiment.
Experimental platform is divided into two parts: the bench and the hanging box.
2 II Function overview
1. Module type structure. It is easy to organize kinds of training projects. That is mean PLC main machine, switch volume input and kinds of simulation experiments units are hanging box type, can combined according to experiment projects, network requirement, later if need to increase experiments, just need increase component, and never out.
2. The experiment hang box is color space diagram, image is clear, close to the actual application of the industrial site, through training o f the device, students can adapt to the scene work soon; Equipment use blue industry pillar profiles, and obtains the national patent; Desktop use high density board that wear-resistant, anti-skidding, 25 mm thick, prevent students peel and cross cut when using.
3. The system using the computer simulation modern information technology means, through the operation, the simulation, the emulation three training level, solves the problem that professional training theory and experiment, practice and the practical application disconnected.
4. Has ground protection, leakage protection, and emergency stop button protection measures.
5. Mating MCGS configuration king software, provide application guidance and application engineering examples.
6. It is easy to learn: supporting educational software, the electronic materials, material database software, project teaching guiding software, and industry simulation software series' upgrade.
7. Easy to teach: use project teaching method and combine with the teaching case. Supporting higher education press multi-media electronic textbooks, multi-media electronic lesson plan production platform and project teaching software, let the teacher's experiment teaching and theoretical teaching easier.
8. Each hanging box input and output terminals are K2 or K4 and is equipped with test leads, safe and convenient.
III. Technical parameter
1. Experiment table dimension:1800×800×1662mm (length×width×height);
2. Working environment: Temperature: -10 ºC ± 40 ºC
Relative humidity: <85% (25 ºC)
3. Power supply:
Input Power: Single phase 110V ± 10% 50/60HZ;
Output Power: Single phase 110V ± 10% 50HZ/60HZ; DC 24V, 3A;
Installed capacity: <250VA;
4. Power control: with overvoltage protection, undervoltage protection, overcurrent protection, leakage protection and other functions;
IV Training project
(1) Motor reversing control experiment
(2) Motor star delta starter control experiment
(3) Control experiment simulated traffic light
(4) Seven segment digital tube experiment
(5) Robotic handling control experiment
(6) Liquid mixed control experiment
(7) Automatic Feeding loading control experiment
(8) Control experiment mail sorting
(9) Light sky tower of control experiment
(10) Responder control experiment
