Product Specifications
| Prod Model: |
20018 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Connect: |
Flange |
| Head Type: |
Round |
| Size: |
According to Customer Needs |
| Standards: |
GB |
| Type: |
Joint |
Product Description
Test Point Pressure Hose Connector,
Test coupling Material: Stainless steel,
Scope of application: Hydraulic oil, gas, corrosive gas,
Heat resistance, 20-200º C
Pressure: 63 (MPa)
Characteristic
1.Perfect surface finish,smoothness without burrs and impurities
2. High precision according to standard. make specific fittings
3.Superior quality and competitive price
4.Widely used in various environment
USES: mainly used in engineering machinery equipment pressure gauge.Work is primarily to test pressure, can bear the high pressure of 63 mpa, stable quality.
Technical parameters
| Mode lorder | The original model | M1 | M2 | L | I | S |
| PT-1 | PT-00 | M10*1 | M12*1.25 | 33 | 8 | 17 |
| PT-2 | PT-00A1 | M10*1 | M16 | 42 | 8 | 19 |
| PT-3 | PT-00A2 | M14*1.5 | M16 | 46 | 12 | 19 |
| PT-4 | DI-3/M10*1 | M10*1 | M16 | 46 | 12 | 19 |
| PT-5 | DI-3/M12*1.5 | M12*1.5 | M16 | 46 | 12 | 19 |
| PT-6 | DI-3/M18*1.5 | M18*1.5 | M16 | 46 | 12 | 24 |
| PT-7 | DI-3/G1/4 | G1/4 | M16 | 46 | 12 | 19 |
| PT-8 | BZ(JB/ZQ4526-86) | M12*1.5 | M14*1.5 | 50 | 12 | 17 |
| PT-9 | KF-1/M10*1 | M10*1 | M16*1.5 | 46 | 11.5 | 19 |
| PT-10 | KF-1/M12*1.5 | M12*1.5 | M16*1.5 | 46 | 11.5 | 19 |
| PT-11 | KF-1/M14*1.5 | M14*1.5 | M16*1.5 | 46 | 11.5 | 19 |
| PT-12 | KF-1/18*1.5 | M18*1.5 | M16*1.5 | 46 | 11.5 | 24 |
Company Information
Ningjin Xinxing hose Co., Ltd. is the production of polyurethane series, nylon series hose hose is mainly a business, injection molding, casting products as a supplement.The company advanced equipment, exquisite technology, complete testing equipment, have the ability to develop new products.The company to the quality of culture of excellence, and strive to build first-class brand, with "honest and trustworthy, benefit sharing" business philosophy, and establish a good corporate image
Our Advantage
1.We can do the designs according to customers' requirements.
2. Reasonable price for long term relationship.
3.Good service for before & after sales.
4.Prompt delivery.
Quality Testing & Packing
(1)Quality test: 100% pressure test and leakage test before packing.
(2) packing details: standard export packing or according to customer's special requirements
IF YOU ARE INTERESTED IN OUR PRODUCTS, PLEASE DO NOT HESITATE TO CONTACT WITH US.
Reminder warm
Note: please describe the specifications, usage, temperature, pressure, fluid medium, the device name and other technical parameters.
The company can be customized to support
Ningjin Xinxing hose Co., Ltd. is a new enterprise development of high performance resin hose
The products have been widely used in petroleum, chemical industry, engineering machinery manufacturing, coal mining, shipbuilding, aviation, automotive, medical equipment and other industries, is the hydraulic and mechanical equipment ideal pneumatic hose, is the most ideal equipment pressure hose, liquid, and powder delivery, high pressure spraying, high pressure cleaning, sand blasting and other fields.
The company has strong technical force and professional design production capacity, have established close cooperative relations with many domestic university and Research Institute, and constantly develop new practical quality products.
Our company supplys different kinds of products. High quality and favorable price. We're pleased to get your Inquiry and we will come back to as soon as possible. We stick to the principle of "quality first, service first, continuous improvement and innovation to meet the customers" for the management and "zero defect, zero complaints" as the quality objective.
