Product Specifications
| Prod Model: |
VT-S |
| Markets: |
South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Tester Used For: |
Varistor & Gdt |
Product Description
Application:
adapt for testing of metal oxide varistor (zinc oxide varistor surge arrester), metal ceramic diode or gas discharge tube.
Characteristic: It can used to measure limiting breakdown, overvoltage ignition components key parameters
Can be pre-set initial action voltage, 20V ~ 1600V continuously adjustable
LCD digital display, accuracy, reliability, intuitive and clear.
When varistors tested to automatically give an accurate 1mA constant current and voltage 0.75U1mA
When the gas discharge tube test, the test voltage to 100V / S rate rises linearly
Select the continuous measurement can be carried out continuously for bulk sample testing
With high short-circuit protection, overcurrent protection, self-test functions
With 190V ~ 260V inherent discrimination, alarm test function
| Technical Parameter | Test Rang | Max. Tolerance | Test Conditions |
Initial Action
Voltage(U1mA) | 0~100V | +/- (2V + 1 d) | 1000+/- 5 Ua |
| 101~1700V | +/- (2%RDG + 1 d) |
| leakage current ( I 0.75U1mA) | 0.1 ~ 199.9uA | +/- 2uA + 1 d) | 0.75U1mA |
| | | | |
| Technical Parameter | Test Rang | Max. Tolerance | Test Conditions |
DC break-down voltage
V sdc | 20~1700V | +/- (2%RDG + 1 d) | Voltage increase rate (100+/-8) V/S |
| Discharge voltage memorize disply time | 1.5~3.5 S |
Fatech Electronic (Foshan) Co., Ltd., is a professional manufacturer on R&D, production and sales of lightning and surge protection products. We have two centers (R & D center, marketing center) and joint venture manufacturing bases in China.
Our main products including:
- Surge arresters for protection of photovoltaic system,
- Surge protection devices for protection of power supply systems,
- SPD surge protectors for protection of signal system,
- Lighting rod,
- Test devices,
- Metal oxide varistors.
Wide range of lighting & surge protection products assured you a one stop shopping location for all your need and professional technical support.
We have an independent testing laboratory, and a complete set of advanced testing equipment, including impulse current generator, the SPD Test System of Thermal Stability, varistor tester, lightning device tester, & TOV testers. We built up a complete quality control system, and strict process control system, product's stability & reliability are qualified by users.
Our company gathered authority technical experts and professionals, including 2 senior engineers, 5 engineers, and 11 excellent technicians with more than five years experience in lightning and surge protection industry. FATECH is well-known registered trademark, our products have achieved certificates of CE, and the company is achieved ISO9001-2008 quality system.
Based on our superior location advantages (It needs 50 minutes drive from Guangzhou Baiyun International Airport, 2 hours drive from Hong Kong), adhering to the business philosophy - "quality first, customer first, sustainable development", we are encouraging independent innovation, brand influence is increasing day by day, the products is selling to more than 30 countries in Europe, Latin America, Asia-Pacific and other regions.
Here are the advantages of us:
1. Stable Quality --- Product performance is stable and reliable.
2. Competitive Price --- Strict cost control system achievements very competitive prices.
3. Fast and always on-time delivery --- Leading technology and production capacity advantage make sure the short & fast delivery and always on-time.
4. ODM & OEM service supplied --- We are able to make not only standard surge protection devices, but also special products according to customer's requirement...
5. Professional on R&D and manufacturing --- With the capability and experience to provide customers with lightning and surge protection applications solutions
