Product Specifications
| Prod Model: |
PCM-580 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Model: |
PCM-580 |
| Brand Name: |
Gashili |
| Speed: |
48PCS/Min |
| Applicable Paper: |
320-450mm |
| Applicable Glue: |
White Glue |
| Power: |
54.05kw |
| Compressed Air: |
1.2m3/Min |
| Weight: |
15t |
| Working Space: |
14000*7000*4000mm |
| Production Time: |
30 Working Days |
| Type: |
Spiral Type |
| Gumming Type: |
Double Side |
| Condition: |
New |
Product Description
Our production line mainly divide into 4 parts:
1. Printing, hem polish part
Roller raw paper, holding rack, use air pressure handle control, the holding rack up and down, lift raw material, the end hand wheel of rotation shaft controls paper left/right position.
Two printing machines: Internal printing machine and external printing machine. Internal printing machine is mainly print number and pattern inside the cone. External printing machine is mainly print color and pattern on top/bottom of cone.
Hem polish machine separate into internal hem polish machine and external hem polish machine.
The function of internal hem polish machine is to grind paper 1/3 thin, it helps cone spindle able to attach paper. The function of external hem polish is to grind paper thin, it helps cone's outside easier to make.
2. Cutting & winding part
Cutting through 8 slices blade form into scissors edge, cut the paper as paper sample required.
Winding part is through 9 pieces gear, which have mechanism and pneumatic components interworking to finish winding process and produce semi- product.
3. Dryer
It has input cone part, drying room and output cone part, Adjust time through cam to prepare. Check the chain running operation regularly.
4. After-finish part
After the product of paper cone came out from dryer, it will through cone dividing, cut V groove, polish bottom opening, string cone, oiling, imprint, curling, napping, eject cone all in one series movement and finishing out qualified cone at last.
Advantage:
Save paper and cost.
Our equipment produced paper cone can save 21mm paper every paper sample than others( which means can make one more cone every 12 cones, one ton can make about 17000pcs cone, one ton can make more 1400pcs cone than others )
Technical Parameter of the Machine:
Model: GLPCL-580/650
Speed: 48pcs/min(normal practicl speed 45-48pcs/min)
Cone size: 3° 30', 4° 20'&5° 57'(can be custom made)
Applicable paper: 320-450gsm
Applicable glue: White glue/Tapioca starch glue
Compressed air: 1.2m3/min, 0.8Mpa
Power: 49KW
Operator: 2~3persons/shift
Weight: ~15T
Needed working space: 14000*7000*4000mm
