Product Specifications
| Prod Model: |
SJZ-92 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Brand: |
Xinxing |
| Raw Material: |
PVC Powder |
| Center Height: |
1100mm |
| Water Circulation Volume For Cooling: |
15 M3/H |
| Pool Volume: |
25m3 |
| Compressed Air Capacity: |
3.0 M3/Min |
| Driving Power Supply: |
3 Phase 380V 50Hz |
| Assembly Total Power: |
67kw |
| Extrusion Line Overall Dimension: |
8000×1500×2300 Mm |
| Frequency Converter: |
ABB |
| Certification: |
GMP |
| Automation: |
Automatic |
| Product Type: |
PVC Pipe |
| Computerized: |
Computerized |
Product Description
Screw construction is specially designed for PVC powder material, through conical clusal method, conduct heterodromous rotation, speed: 1-34.7r/min.
Screw material: using high quality alloy steel 38CrMoAIA, by nitriding treatment under high temperature, nitriding depth: 0.5-0.7mm, surface hardness: HV740-940.
Screw core temperature control: using internal recycle constant temperature device, for heat conduction then control the temperature of screw core.
Barrel material: high quality alloy steel 38CrMoAlA, by nitriding treatment under high temperature, nitriding depth: 0.6-0.7mm, surface hardness ≥ HV940.
Barrel temperature control system
Heating zone: aluminium casting heating ring + stainless steel shell + cooling fan
Heating zone qty: 4 zone, heating total power 18kw
Cooling fan power: 3x0.55kw/set
Head connector: 38CrMoAIA, by hardening, tempering and surface nitriding treatment, runner surface is plated with hard chrome(Cr), using confluence format.
Quantitative feeding system
Using stainless steel feeding hopper ( equipped with 200kw spring automatic feeding device)
Quantitative feeding device
Feeding motor power: 1.1kw three phase asynchronous motor, connected with micro cycloid pin transmission, motor speed range: 10 ~1500 r/min; Feeding screw speed range: 1 ~ 50 r/min
Feeding device speed regulator, controlled by AC motor ABB frequency converter
Vacuum air exhaust device
| Vacuum pump | direct connection water ring vacuum pump 1 set |
| Vacuum pump power | 1.5kw
|
| Vacuum pump motor working format | three phase asynchronous motor |
| Vacuum degree | 0~0.075 Mpa |
IF YOU WANT TO KNOW MORE INFORMATION ABOUT OUR PRODUCTS,CONTACT ME FREELY.
XINXING brand was founded in 1993 at zhoushan city, Zhejiang province, China for barrel and screws manufacture;
Shanghai XINXING was founded in 1999 at Shanghai City, China for complete extrusion machine manufacture for PVC/PE pipe and pelletizing line.
With more than 20 year's experience XINXING has the ability to design and produce different extrusion line for PVC/PE/PP/PET/PS/ABS...Different raw materials with different final products like the PIPE, PROFILE, BOARD, SHEET, PELLET and so on.
And XINXING has exported all the lines to more than 30 countrys in all over the worl.
The mainly market for XINXING is Middle East, Eest Euro, South Asian and South American.
With 20 year's working in the interner market, XINXING has got strong market feedback, and set up reliable agent relation in the above market.
XINXING has the ability, the experience and the willing to offer professional and strong support to all the customer.
