Product Specifications
| Prod Model: |
XMY-P111 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| 2*Motors: |
Taiwan Teco |
| 2*Frequency Converter: |
Japan Mitsubishi |
| Total Power: |
5kw |
| Process: |
Paper Machine |
| Usage: |
Office Paper Machine |
| Automatic Grade: |
Automatic |
| Computerized: |
Yes |
| Certification: |
CE |
| Type: |
Slitting Rewinder |
Product Description
Feature:
Main motor: Driven by one A. C motor with 2 stages type length counter to make machine stops accurately.
Rewind device: Rewind controlled by 3 surface rollers, and surface tension is adjustable for different materials and request.
Electricity Device: Equipped with 2 stage preset length counter, which provide machine stops accurately and smoothly.
Rewind Mode: Equipped with separated shaft type unwind base, auto web guide and auto unwind tension controlled.
Unwind Base: Separate type with hydraulic core chunk can be equipped for effcient and quick performance on jumbo roll change.
Optional:
Unwind Pick Up Lift: For loading jumbo roll on the machine quickly and time saving.
Slitting Device: Able to be equipped with air score knife and trim removable unit for trimming at both side and size slitting,
Tabbing Device: Automatic tabbing on the web during the production.
Main Technical Parameters:
Machine width: 0.5M-1.1M
Max. Unwind diameter: 1000MM
Max. Rewind diameter: 200MM
Max. Rewind speed: 200M/MIN
I. D. Of paper core: 12-50MM
Min slitting width: 30MM
Air pressure: 6Bar
1). Professional in making slitter rewinder, roll cutters.
2). Yearly Production Capacity ---200-300 sets.
3). Built with hi-tech control systems.
4). From Taiwan&Japan newest technology reasearch.
5). ISO9001: 2008, SGS, CE, Gold supplier certificated.
6). Good after-sale service and support team.
7). Promote reply within 24 hours.
8). Be conveniently near Shanghai.
Our aim: Customer first, credibility first.
