Product Specifications
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Product Description
Application:
Used for measuring thickness and corrosion of pressure vessels, chemical equipment, boilers, oil storage tanks, etc. In industries of petroleum, shipbuilding, power station, and machine manufacturing.
Model: TM8816 TM8816C
Measuring range (metric/imperial): 1.0-200mm, 0.05-8inch
Operating principle: ULTROSONIC
Materials measured: Any hard materials, including steel, cast iron, aluminum, red copper, brass, zinc, quartz glass, polyethylene, PVC, gray cast iron, nodular cast iron and other materials
Sound velocity: 500-9000m/s
Lower limit steel pipes: 15x2.0mm, 20x3.0mm determined by the transducer
Calibration block: Included
Resolution: 0.1mm(TM8816C 0.01mm)
Accuracy: ± (0.5%n+0.1)
RS232C interface: With RS232C
Power supply: 4x1.5V AAA (UM-4)battery
Battery indicator: Low battery indicator
Operating conditions: 0-+45(32-104), ≤ 90%RH
Dimensions: 120x62x30mm
Weight: 164G(not including battery)
Dalian Teren Industry Instruments Import and Export Co., Ltd. is setting up in the beautiful city Dalian with the sea surrounded. We pay more attention on the running of instruments, our products include the ultrasonic flow meters, ultrasonic level meters, ultrasonic water meters, ultrasonic thickness meters and many the same series products.
Our business are estabished on the basis of good quality, good price and honest. All the customers will have our best services and share the most reasonable prices. We have very good cooperation with many enterprises in domestic and abroad. We have the good relationship with our partners in Australia, USA, UK, India, Italy and many other countries. We also have many domestic suppliers, and we are sure to supply you the satisfacted produtcs and good serives.
If you are interested in any items, or your customers require to fill, please contact us, we will provide you the products with high quality and good services, and reply you as soon as possible.
