Product Specifications
Prod Model: |
EG_N530 |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Resolution: |
1440*900 |
USB Port: |
3 USB Ports |
Size Of Host: |
Any Kind |
Supporting Memory Capacity: |
Share With Host |
Max. CPUs: |
Unlimited |
CPU Type: |
All Windows |
Product Description
Thin Client PC Share Terminal---Are you still buy 10, 20 or more computers while actually 1 or 2 will do? If so, do change from now on! 4 USB port, wireless/ USB mouse and keyboard supported. Excellent office work and also perfect in entertainment. With WinCE OS buildin, Thin Client PC Share Terminal can work sdand alone without host.
Thin Client PC Share Terminal share one computer with up to 100 more users, 1 traditional desktop computer+ 30 Thin Client PC Share Terminals= 31 traditional desktop computers
Thin Client PC Share Terminal N530 let 2 to 100 more users share one desktop computer, turns 1 PC into 30 more PCS.
Thin Client PC Share Terminal N530 virtual desktops share the excess power of standard PCS and make computing simple and affordable. When using Thin Client PC Share Terminal N530, you can save money by sharing the cost of a single PC among multiple users.
Thin Client PC Share Terminal over view:
Most PCS are set up with multiple user accounts. Each user gets their own software, settings, screen colors, and so on...But only one person can use the PC at a time. Thin Client PC Share Terminal changes all that. Thin Client PC Share Terminal with desktop virtualization software allows all of the accounts to be used at the same time.
Why we need multiple user accounts to be used at the same time?
We can't live without PCS, but we need to learn how to live with them: They consume too much electricity and generate too much e-waste. A typical PC takes 110 watts to run, and there are almost a billion of them on the planet.
Today's PCS are so powerful that we no longer need one for each person. We can tap into the excess power in one PC and share it with many users. Thin Client PC Share Terminal technology uses just 1 to 5 watts, lasts for a decade and generates just a few ounces of e-waste.
Benefits of Thin Client PC Share Terminal:
Thin Client PC Share Terminal is the greenest computer in the world. Bellowing is some benefits of Thin Client PC Share Terminal:
1. Save computer costs & electricity
Thin Client PC Share Terminal systems save you 75% on hardware, and since they draw less than 5 watts, you reduce your energy footprint by as much as 90% per user. Thin Client PC Share Terminal devices produce practically no heat, they reduce the need for energy-consuming air conditioning. Electricity savings alone can pay for the Thin Client PC Share Terminal virtual desktops in as little as one year.
2. Easy to install, simple to manage
Plug in your Ethernet cable, mouse, keyboard, and monitor. Install the included Thin Client PC Share Terminal software on the shared PC. It just takes a few minutes. You now have added multiple users, each with their own rich Windows or Linux environment.
3. Simultaneous desktop operation
Each Thin Client PC Share Terminal accesses the host PC OS and runs its user applications concurrently and independently. So many users can run one operating system at the same time now.
4. Small efficient design
You can set the Thin Client PC Share Terminal to the backside of your LCD monitor, takes no extra room in your desk or office.
Since the Thin Client PC Share Terminal has no moving parts, it runs completely silently and saves energy by drawing less than 5 watts. Sometimes you won't feel their existing, only see the LCD monitor, keyboard and mouse on your desk. See how small it is.
5. Powerful and flexible
With this small Thin Client PC Share Terminal, you can surf internet, listen to music, send & receive e-mails, enjoy audio and video entertainment besides doing your daily office work. With the MIC port, you can even talk with your friends online.
Hardware |
Size |
Access Device: 128*128 *26 mm
Shipping Size: 220*137*47mm |
Weight |
N530Terminal: 240g
Shipping Weight (includes power adapter, packaging, documentation, etc. ): 620g |
Power Supply |
Input: 100-250 VAC, 50-60 Hz; Output: 5 VDC, 2 A
Nominal consumption: 5 Watts |
Front LED Indicators |
Power: connection to power supply
LAN: connection to network
Ready: connection to host PC |
Connection to Host PC |
Standard Category 5 or 5e UTP cable or 6 STP cable (No limitation) |
Video Resolution |
Support 640*480, 768*576, 800*600, 1024*768, 1152*864, 1280*1024, 1440*900 720*480, 1280*800, 1280*960, 1368*768, 1360*768, 1366*768, 800*600 @75Hz, 1024*768 @75Hz |
Audio |
Stereo output via speaker port |
USB port |
4 USB ports on access device for any kind USB facilities |
Internal HW |
l All solid-state design, no moving parts, no fans, no local user storage
l Eglobal System-on-Chip with SDRAM and flash
l Embedded Eglobal operating firmware (no local user OS) |
Reliability (MTBF) |
> > 100, 000 hours (calculated using Bellcore Issue 6 TR-332, Case 2, Part I at 40° C) |
HW Security |
No local user storage |
TERMINAL SERVICES SOFTWARE |
Max # Users Per PC |
No limitation when using a server host OS (i. e. Windows Server 2003)
max 25 users when using a desktop OS (i. e. Windows XP) |
User Software |
PC Station terminal services software |
Supported Operating
Systems |
All Windows OS (Professional) |
SYSTEM REQUIREMENTS AND OPTIONS |
Kit Contents |
EGLOBAL PC STATIONS Kit includes access terminal, power supply, software installation & user’ s guide and other peripherals are NOT included and must be purchased separately. |
Recommended host configuration according to ures number |
User No. |
1-4 |
5-10 |
11-20 |
21-30 |
31-50 |
51-57 |
71-100 |
Host PC
CPU& Memory |
> 2.4
GHz P4
with
512MB |
> 3.0
GHz P4
with
2GB |
Intel P4
3.2GHz
with
3GB |
XEON3.2CHz
or
XEON2.8GHZ
DUAL
with 4GB |
XEON E5506*2
4G*4
DDR3/1333
ECC REG |
XEON E5506*2
4G*6
DDR3/1333
ECC REG |
XEON E7520*2
16G*4
DDR3/1333
ECC REG |
