| Supplier: | Shenzhen Junfirer Technology Development Co., Ltd. |
|---|---|
| Price: | Negotiable/Set |
| Min Order: | 100/Set |
| Quantity:: | |
| Trade Terms: | FOB,CFR,EXW |
|
|
| Prod Model: | JFTC410 |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Multi-Case: | Optional |
| Max. CPUs: | 1 |
| CPU Type: | PC Share/Terminal |
| Supporting Memory Capacity: | ≤8GB |
| Case | C09B(optional) |
| Dimension | 215x190x60mm(L*H*W) |
| Packaging dimension: | 360*335*120mm, 4 to one export carton |
| Weight | 2Kg (Reference) |
| Power Consumption | 20W |
| Onboard CPU | Intel® Atom™ processor D410 (single-core / 1.66 GHz /512 KB L2 cache) |
| Memory |
• 512M DDR2 RAM • Single-channel DDR2 with two connectors for 800 / 667 MHz memory support (4 GB max) |
| Chipset | Passively cooled, Intel® NM10 Express Chipset |
| Hard Disk | Standard 8 GB SSD (support up to 32GB and 2.5 inch SATA HDD ) |
| Onboard VGA |
Intel® Graphics Media Accelerator 3150 Graphics Controller |
| Onboard LAN | Realtek* 10/100/1000 Mb/s Ethernet Controller |
| Audio Solution |
• 2+2-channel Intel® High Definition Audio2 (with multi-streaming) • Front-panel mic / headphone header |
| I/O Controller |
• Two SATA ports (fully shrouded) • Two PS/2 ports • Two Serial headers • One PCI port • Three USB ports |
| Front-Panel Connectors |
• Reset, power on/off • HD LED, Power LEDs • USB 2.0 headers • Audio header |
| Back-Panel Connectors |
• 4 USB 2.0 ports • 1 RJ-45 LAN port • 3 Audio header • 1 PS2 mouse port • 1 PS2 keyboard port • 1 VGAport |
| Operating System |
Standard Windows XP Embedded Support Windows 2000/XP/Vista/Windodws 7/Windows 2008 |
