| Supplier: | Sanmenxia Kind Ind. Trade Co., Ltd. |
|---|---|
| Price: | Negotiable/Piece |
| Min Order: | 1/Ton |
| Quantity:: | |
| Trade Terms: | FOB,CFR,CIF |
|
|
| Prod Model: | 0.1mm-0.5mm |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Application: | Motor |
| Type: | Insulation Paper |
| Chemistry: | Organic Insulation |
| Thermal Rating: | B 130 |
| Material: | Wood Pulp |
| Items | Standard IEC60641-3-2(P.4.1) | ||
| Thickness Deviation | ±10% max. | ||
| Density | 1.0 -1.20 g/cm3 | ||
| Tensile strength MD | ≥ 80 Mpa | ||
| Tensile Strength CMD | ≥ 40 Mpa | ||
| Tensile strength after folding MD | A | B | |
| ≥ 35 Mpa | ≥ 40 Mpa | ||
| Tensile strength after folding CMD | ≥ 60 Mpa | ||
| Elongation | MD | ≥ 2.0% | |
| CMD | ≥ 7.0% | ||
| Elongation after folding | MD | ≥ 1.2% | |
| CMD | ≥ 5.0% | ||
| Ash Content | ≤ 1.0% | ||
| PH Value of Aqueous Extract | 6 - 9 | ||
| Conductivity of Aqueous Extract | ≤ 8.0 mS/m | ||
| Electrical Strength in air | Thickness | A | B |
| 0.1mm | ≥ 9 KV/mm | ≥ 9 KV/mm | |
| 0.15 0.25mm | ≥ 10 KV/mm | ≥ 10 KV/mm | |
| 0.30 0.35mm | ≥ 10 KV/mm | -- | |
| 0.40 0.50mm | ≥ 9 KV/mm | -- | |
| Electrical Strength after folding in air | Thickness | A | B |
| 0.1mm | ≥ 7 KV/mm | ≥ 7 KV/mm | |
| 0.15 0.25mm | ≥ 8 KV/mm | ≥ 8 KV/mm | |
| 0.30 0.35mm | ≥ 8 KV/mm | -- | |
| 0.40 0.50mm | ≥ 7 KV/mm | -- | |
| Moisture Content | ≤ 8 % | ||
