Thql Miniature Circuit Breaker (THQL)

Name: Thql Miniature Circuit Breaker (THQL)
Brand: China-Manufacturer-Directory.com
SKU: 681900652
Availability: InStock
Rating: 4.3 (133 reviews)

Supplier:	Yueqing Supower Electric Co., Ltd.
Price:	Negotiable/Piece
Min Order:	500/Piece
Quantity::
Trade Terms:	FOB,CFR,CIF

Product Specifications

Prod Model:	THQL
Type:	Circuit Breaker
Function:	Overcurrent Protection~@~Circuit-Breaker Failure P
Breaking Capacity:	Low Voltage Circuit Breakers
Certification:	CE
Operation:	Electric Type
Installation:	Insert
Speed:	Normal Type Circuit Breaker
Structure:	Conventional Circuit Breaker

Product Description

THQL type mini circuit breakers series are low price and high quality offer miniature circuit breaker (MCB )
THQL mini circuit breakers applies to electromagnetic design which possesses the functions of overload
And short circuit protection. This series miniature circuit breaker MCB is widely used for illumination and distribution in industry and commerce
Because of its characters of pleasing out-look, light weight, reliable performance, high breaking capacity. The design MCB is AC 220V, AC230V and AC240V and circuit electronic protection.
For rated current under 63A (6KA)and for rated current from 80A to 125A, the capacity is 10KA, easy and mainly adapted to the circuit AC 50Hz, 230V in single pole, 415V in double, three and four poles for protecting overload and short circuit and
Clearly for operation etc. Meanwhile, this series miniature circuit breakers also used turning on off the electric apparatus and lighting circuit under the normal condition and also used for infrequent switching line under the normal condition. Miniature circuit breaker complies with the standard of IEC60898.

Model	THQL1' THQL1/2'
Number of Poles	1P,2P,3P
Rated Current(A)	6,10,16,20,25,32,40,50,63,80,100A
Rated Voltage(V)	110/220(1P),240/415(2P),415(3P)
Release type	B,C,D
Breaking Capacity(A)	10000
Electrical Life	6000
Mechanical Life	20000

The over-current tripping unit protection feature

Sequence NO .	Release	Test current I/In	Start state	Tripping time	Expected results
1	B,C,D	1.13In	Cold state	t≤1h	Not tripping
2	B,C,D	1.45In	Start right after the serial NO . 1 test	t<1h	Tripping
3	B,C,D	2.55In	Cold state	1s	Tripping
4	B C D	3In 5In 10In	Cold state	t≤0.1s	Not tripping
5	B C D	5In 10In 20In	Cold state	t<0.1s	Tripping
