TK-2000 TK-3000 Portable two way radio:
Main Features:
1. Frequency Range: 350-390/400-430/440-480MHz
2. Output Power: 4W
3. 16 Channels with Scan Function
4. Programmable Function Key with Hold
5. All-in-one Package(Antenna, Li-ion Battery, Rapid Charger and Belt Clip)
6. IP54 dust and water intrusion standards
7. MIL-STD 810 C, D, E, F & G environmental standards
8. QT / DQT signaling
9. DTMF Enc. (PTT ID, Autodial)
10. Priority Scan
11. Windows® Programming and Tuning
12. Wide/Narrow Channel Bandwidth
13. VOX ready
14. Battery-Saver
15. Busy Channel Lockout
16. Time-Out-Timer
17. Low-Battery Alert
18. Tri-Colour LED
19. Wired Clone
GENERAL |
Frequency Range | 350-390/400-430/440-480 MHz |
Number of Channels | 16 channels |
Channel spacing Wide / Narrow | 25 kHz / 12.5 kHz |
Channel Step | 5, 6.25 kHz |
Operating Voltage | 7.5 V DC ± 20% |
Battery Life | Approx. 10 hours |
Operating Temperature | -20ºC to +60ºC |
Frequency Stability | 5 ppm |
Antenna impedance | 50 Ω |
Channel Frequency Spread | 30 MHz |
Dimensions (W x H x D), Projections not included | 54 x 113 x 24.9 mm (include battery) |
Weight (net) | Approx. 203 g (include battery) |
FCC ID | ALH437200 |
FCC Compliance | Parts 15 / 90 |
RECEIVER |
Sensitivity (12 dB SINAD) Wide / Narrow | 0.25 μV / 0.28 μV |
Selectivity Wide / Narrow | 70 dB / 60 dB |
Intermodulation Distortion Wide / Narrow | 65 dB / 60 dB |
Spurious Response | 65 dB |
Audio Distortion | Less than 5% |
Audio Output | 500 mW / 8 Ω |
TRANSMITTER |
RF Power Output High / Low | 4 W / 1 W |
Spurious Response | 65 dB |
Modulation Distortion Wide / Narrow | 16K0F3E / 11K0F3E |
FM HUM & Noise Wide / Narrow | 45 dB / 40 dB |
Audio Distortion | Less than 5 % |
Packaging & Shipping
· 1x walkie talkie
· 1x battery
· 1x Antenna
· 1x Belt Clip
· 1x User's Manual
· 1X Power adapter
