Tns 6kVA Three Phase AC Voltage Regulator and Home Voltage to Industrial Voltage Power Inverter Power Supply Inverter

Product Specifications

Prod Model:	TNS-6kvA Three Phase AC voltage regulator
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Model No.:	Tns-6kVA
Case:	Metal Plate
Colour:	Gray 7035
Phase:	Three
Type:	DC/AC Inverters
Power Source:	Electric Power
Output Power:	6
Nature Of Wave String:	Non-Lack Fidelity Waveform
Brand:	Anscnlec

Product Description

APPLICANT
TND/TNS (SVC) single/three phase high precise voltage stabilizer which are composed of contact type self-coupling voltage regulator, automatic sampling control circuit and servo motor, when the input voltage change, sampling control circuit for sampling, amplifying, the servo motor according to the desired direction, drive voltage regulator jib, adjust voltage until the output voltage conforms to the rating, voltage regulator and to achieve.

This product is small volume, light weight, small output waveform distortion, stable and reliable. In order to ensure product quality, our company introduced foreign advanced technology, key parts adopt imported parts.
USE OCCASIONS
This product is suitable for small and medium-sized power needs to be regulated power electric equipment, is the industrial production, scientific research and medical and health fields such as ideal regulated power supply, its minimal power consumption, can be continuous use for a long time.
USE CONDITIONS
TND·TNS (SVC) series voltage regulator should be used in indoor, when normal conditions as follows:
1, the ambient temperature: - 5 ºC ~ + 45ºC degrees Celsius
2, altitude: not more than 1000 meters
3, relative humidity: 90% or less
4, the installation place should be no impact stabilizer of the insulation gas, steam, chemical deposition, dust, dirt and gas explosion and corrosive substances
5, installation site should be no serious jolt and shock
if not meet the requirements of the special conditions of use, shall be in consultation by using unit and my company
MAIN SPECIFICATION

Phase number	Three phases	Single phase
Input voltage(V)	Line voltage(280-430)	Phase voltage(160-250)
	Can choose (230-430)Special low voltage	Can choose(130-250)Special low voltage
Output voltage(V)	Line voltage 380V±3%	Phase voltage 220V±3%
Frequency Hz	50~60	Waveform distortion	non
Efficiency	≥95%	relative humidity	less than 90%
precision	±3%	temperature	<70ºC(full load)
Stability time	<0.5s(input voltage change within 10%)	overvoltage protection	245±5V
compression strength	>1500V	delay	shory delay 3-7s

TND· TNS (SVC) SERIES MODEL SIZE

Phase number	Model	Output capacity	Output current	Dimension	Weight
		(KVA)	(A)	(W×L×H)cm	(Kg)
TND single phase series	TND-0.5	0.5	2.25	19×16×14	4
	TND-1	1	4.5	21×19×17	5.5
	TND-1.5	1.5	6.7	21×19×17	5.8
	TND-2	2	9	29×24×20	10
	TND-3	3	14	29×24×25	12
	TND-5	5	23	36×22×29	15
	TND-7	7	32	36×22×29	16.5
	TND-10	10	45	42×24×36	27
	TND-15	15	68	42×38×76	64
	TND-20	20	90	42×38×76	70
	TND-30	30	136	45×43×87	95
	TND-5 VERTICAL	5	23	32×28×46	17
	TND-10 VERTICAL	10	45	36×28×51	36
TNS three phases series	TNS-1.5	1.5	2.25	48.5×22.5×17	20
	TNS-3	3	4.5	48.5×22.5×17	24
	TNS-4.5	4.5	6.7	48.5×22.5×17	28
	TNS-6	6	9	36×28×68	34
	TNS-9	9	14	38×32×78	43
	TNS-15	15	23	44×36×78	68
	TNS-20	20	30	52×40×86	85
	TNS-30	30	45	49×46×97	91
	TNS-40	40	60	64×57×118	175
	TNS-50	50	75	64×57×118	185
	TNS-60	60	90	64×57×118	196
	TNS-80	80	120	67×55×132	233
	TNS-100	100	150	67×55×132	273
