Trinocular Bright & Dark Field Upright Metallurgical Microscope (LM-306)
Product Specifications
| Prod Model: |
LM-306 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Mechanical Stage Travel: 50mm*50mm: |
110V-220V |
| Upright Metallurgical Microscope: |
Research Level |
| Trinocular Tube: |
Inclined 30 Degree |
| Stage Travel: |
75*50mm |
| Stage Size: |
210*140mm |
| Objective Lens: |
5X, 10X, 20X, 40X |
| Eyepiece: |
Wf10X/22 |
| Stereoscopic Effects: |
Yes |
| Filter Color: |
Green, Blue and Yellow |
| Bright & Dark Field Objective: |
50X, 60X, 80X, 100X |
| Magnification: |
500-1000X |
| Type: |
Metallographic |
| Number Of Cylinder: |
≥Three |
| Mobility: |
Desktop |
| Shape: |
Triangular Prism |
| Principle: |
Optics |
Product Description
Trinocular Bright & Dark Field Upright Metallurgical Microscope (LM-306)Usage
Upright bright & dark field Metallurgical Microscope LM-306 is used to observe and identify the structure of various metal and alloy, widely used in institute and laboratory
Feature
1) Infinitive optical system assure the excellent optical functions
2) Kohler illumination
3) For bright and dark field observation
4) For Differential Interference contrast observation, DIC observationStandard delivery
Main unit: 1pcs
5x, 10x, 20x, 40x bright & dark field objective lens: 1pc each
12V/50W Osram halogen bulb: 1pcs
Green, blue and yellow filter: 1pcs each
Polarizer and analyzer: 1pcs
Anti-dust cover: 1pcs
Optional accessories
50x, 60x, 80x, 100x bright & dark field objective
DIC observation unit
0.5x, 1x, C-mount camera adapter
5M Pixel digital CCD camera
Analysis software
Examine software
Technical specification| Eyepiece | WF10X/22 |
| Objective lens | 5x, 10x, 20x, 40x |
| Mechanical movable stage | Size: 210*140mm
Travel: 75mm*50mm |
| Interpupillary distance | 53mm-75mm |
| Trinocular tube | Inclined 30º. |
| Diopter adjustment | ±5 diopter |
| Illumination | 12V/50W halogen bulb |
| Power supply | 110V/220V |
