Product Specifications
| Prod Model: |
TSC-1000 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Dimension 135mm(W)*84(L)Mm*28mm(H): |
Weight 0.5kg |
Product Description
TSC-1000 ASI/SPI Adaptor can make the MPEG TS exchange between SPI and ASI, which is the necessary accessorial equipment of the DTV system. The TSC-1000 ASI/SPI has 2 types: TSC-1000-1 convert MPEG TS from SPI parallel interface to the DVB ASI serial interface. TSC-1000-2 convert MPEG TS from DVB-ASI serial interface to SPI parallel interface.
MAIN FEATURES
Input/output between 0~216Mbps, adapted automatically
100m ASI supported
MPEG-2 TS supported
SPI adopt LVDS level input
9V single power supply
Low power loss
Portable
SPECIFICATION
ZASI connector
1 DVB-ASI
Comply to the EN50083-9
188/204 bytes packet adapted automatically
Max. Rate 216Mbps
Level 800MVP-p
Return loss 7dB
Connector BNC, 75ohm
SPI connector
1 DVB SPI(LVDS)
Connector dB-25 FEMALE
Max. Rate 108Mbps
Power
Voltage 9V, 500mA
Consumption Max. 2W
Mechanical Parameter
Operational temperature 0~45 BR> Storage temperature -20~70 BR> Humidity 10%-95%
Dimension 135mm(W)*84(L)mm*28mm(H)
Weight 0.5kg
