Product Specifications
| Prod Model: |
TSL8-63 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Protection Degree: |
IP20 |
| Breaking Capacity: |
Low Voltage Circuit Breakers |
| Certification: |
TUV |
| Operation: |
Manual Type |
| Arc-extinguishing Medium: |
Air |
| Speed: |
Normal Type Circuit Breaker |
| Function: |
Overload and Short-Circuit Protection |
| Structure: |
RCCB |
| Poles Number: |
2p, 4p |
| Installation: |
DIN Rail |
Product Description
APPLICATION:
1. The RCCB can cut off the fault circuit immediately on the occassion of shock hazard or earth leakage of trunk. Thus, it is suitable to avoid the shock hazard and fire caused by earth leakage.
2. The RCCB is mainly used in varieties of plants and enterptised, building construvtion 1 Phase 240V and 3 phase 415V 50/60Hz.
3. The products comply with IEC61008.
SPECIFICATION:
| Number of Poles | 2P, 4P |
| Rated Current (A) | 16, 20, 25, 32, 40, 50, 63, 80, 100 |
| Rated Residual Operating Current (lΔn)(mA) | 10, 30, 100, 300, 500 |
| Rated Residual Non- Operation Current (lΔno)(mA) | <=0.5lΔn |
| Rated Voltage | 2P: AC 240V |
| 4P: AC 415V |
| Residual Operating Current Scope | 0.5lΔn~lΔn |
| Residual Current Off-time | <=0.3S |
| Breaking Capacity | 3000A |
| Endurance | 4000 |
| Protection Degree | IP20 |
Why us(Residual Current Circuit Breaker)?1. We have extensive experience in low tension electric items and illumination products. We have been dealing the line for more than 21 years.
2. The prices of our products are very reasonable because our network of raw material supply, spare parts and goods. And our factory is efficient, covering an area of 13,000 m².
4. Our group of professional inspectors supervising the quality for your every order. Our products have obtained TUV, SEMKO, CE, CB, and ROHS certificates.
5. We have particular designers in charge of packing.
6. We have experienced salesmen to handle business for you specially.
About us Residual Current Circuit Breakernearly 20 years for Crimping Tool
1. More than 23 years' experience. We have extensive experience in low tension electric items illuminaiton products.
2. Reasonable price. Good network of raw material supply, spare parts and goods and efficient factory covering an area of 13,000 m².
3. Reliable quality. We have professional inspectors supervising the quality during the production. Our products have obtained TUV, SEMKO, CE, CB and RoHS certificates.
4. Favorable service. We have experienced salesmen to handle business for you specially.
5. Attractive packing. We have particular designers in charge of packing material in a unique style.
OUR PRODUCING LINE (Residual Current Circuit Breaker)![]()
Our office (Residual Current Circuit Breaker)![]()
