Two-Head Automatic Glass Drilling Machine

Name: Two-Head Automatic Glass Drilling Machine
Brand: China-Manufacturer-Directory.com
SKU: 689271472
Availability: InStock
Rating: 4.8 (132 reviews)

Supplier:	Guangdong Shunde Timbery Technology Co., Ltd.
Price:	Negotiable/Piece
Min Order:	1/Piece
Quantity::
Trade Terms:	FOB,CFR,CIF

Product Specifications

Prod Model:	BSZ2000-2
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Type:	Glass Drilling Machine
Certification:	CE
Control System:	PLC

Product Description

1.1 Glass drilling machine can connect with the edging machine and washing machine.
1.2 The drilling and feeding is automatically, and thickness is adjusted by computer.
1.3 The machine can drill two holes at the same time.
1.4 An ideal glass drilling machine, easy to operate and maintain.

1	Diameter of holes	ø4~ø45mm
2	Drilling depth	4~25mm
3	Max.dimensions of pieces to be drilled	2000mm()xN(N=1.2.3^)
4	Min.dimensions of pieces to be drilled	1000x550mm
5	The total number of spindles	4pcs(2sets)
6	Rotation speed of spindles	900~3000r/min
7	Voltage	~380V/50HZ
8	Drilling motor power	4-1.5kw
9	X-axis motor power	2-600kw
10	Y-axis motor power	1.5kw
11	Z-axis motor power	4-13Nm
12	Water pump	2-250W
13	Total motor power	≈12kw
14	Pressure of compressed air	0.5~0.6MPa
15	Table height	900mm
16	Weight	3900kg
17	Machine overall size	4300x5000x2200mm
18	Electric-box overall size	850x530x1800mm

Guangdong Shunde Timbery Technology Co., Ltd. Locates in Shunde Dist, Foshan City. It is a professional and innovative glass tempering machine manufacturer with patented technologies. The glass tempering machine, with the leading energy saving technique and high quality glass tempering, has a good common evaluation by our customers.

Main products: Flat/Bending Glass Tempering Furnace, Double Chambers Tempering Furnace.

Adhering to the principle of "Quality First and Customer paramount", we provide our products with lead-edge technologies to customers.
