Rubber Refining Machine / Two Roll Rubber Refining Machine
Function:
Mainly for rubber warming, plasticating, mixing, and sheeting.
Technical Parameters:
Model No.: XK-400
Roll working diameter(mm): 400
Roll working length(mm): 1000
Linear velocity of the front roll(m/min): 18.65
Friction ratio of rolls: : 1: 1.27
Max. Nip of rolls(mm): 10
Feeding capacity per batch(kg): 18~35
Motor power(kW): 37
Overall size: L * W * H (mm): 4350*1850*1785
Features:
1. Rollers: Made of alloy chilled cast iron, hollow, with smooth surface after precision grinding processing.
2. Reducer: Noise is low, and using life is long.
3. Bush: Three types, nylon, copper, and roller bearing
4. Nip adjustment: Two types, manual and electric
5. Lubrication of roll: Two types, oil lubrication and grease lubrication
6. Emergency stop device: With emergency button and lever, to ensure the safety of operator and equipment.
Quality Control:
BEFORE PACKAGE, LOAD TEST WILL BE CARRIED OUT, TO ENSURE THE CUSTOMER CAN USE THE MACHINE IMMEDIATELY AFTER INSTALLATION.
Our Services:
1. One year warranty for free.
2. Lifetime technical support.
3. Engineers available to service machinery overseas.
4. Any demand, we will give feedback within 24hours.
Welcome to make a field inspection of our factory.
We are always pleased to serve you at any time.
Rubber Refining Machine Model No. | XK-160 | XK-230 | XK-250 | XK-360 | XK-450 | XK-560 | XK-550B | XK-660 |
Roll working diameter(mm) | 160 | 230 | 250 | 360 | 450 | 560/510 | 550 | 660 |
Roll working length(mm) | 320 | 600 | 620 | 900 | 1200 | 1530 | 1500 | 2130 |
Linear velocity of the front roll(m/min) | 8.95 | 10.21 | 14.1 | 16.25 | 24.26 | 27.72 | 27.94 | 28.6 |
Friction ratio of rolls | 1:1.35 | 1:1.19 | 1:1.17 | 1:1.25 | 1:1.27 | 1:1.2 | 1:1.22 | 1:1.24 |
Max. nip of rolls(mm) | 4.5 | 7 | 8 | 10 | 15 | 15 | 15 | 15 |
Feeding capacity per batch(kg) | 1~2 | 6~10 | 8~15 | 20~25 | 25~50 | 35~50 | 50~60 | 165 |
Motor power(kW) | 5.5 | 15 | 18.5 | 30 | 55 | 90 | 110 | 245 |
Overall size: L * W * H (mm) | 1380*860*1320 | 2800*1200*1120 | 3400*1500*1800 | 3780*1850*1750 | 5200*2380*1840 | 5845*2284*1978 | 5870*2475*2045 | 7465*3662*2080 |
