HDMI A Type To D Type Cable
Specification:
. HDMI 19pin male to HDMI 19pin male;
. Connector: 24k gold plated/nickel plated;
. Support all HDMI devices including 1.3/1.4 version;
. Supports resolution up to 1080P;
. All conductors and the shields(braid and drain) are copper;
. Triple shields, prevents the EMI effectively;
. Perfect for connecting HDMI monitors, A/V recievers, and HDTV;
. CL3 cable can satisfy wiring HDMI cables in construction;
. Can provide quite long HDMI cable with amplifying signal without power source;
. Over 100 models for HDMI cable are available;
. ATC certified
Features:
. A premium quality 1.3/1.4 HDMI to HDMI cable is suitable for use in HDTV, home theater, DVD player, projector and other devices;
. 24K gold plated connector resist corrosion and ensures an optimum connection for maximum signal transfer;
. High pure oxygen free cooper conductor for maximum conductivity and reliability;
. Compatible with multiple audio formats from stereo to muti-channel cound;
. Transfer digital audio&vedio signals at wrap speed of 10.2 gigabytes per second;
1.4V Features:
3D- Capability to pass 3D stereoscopic signal formats
4K- 4096X2160/24 video resolution support for commercial applications such as Digital Movie Theaters, CAD, Post Production, Graphics and etc.
HDMI Ethernet Channel- Allows 100 MB/s Ethernet between two HDMI connecting devices
Audio Return Channel- Allows audio to be returned from display back to HDMI source for amplification and display
Supports all SD, HD, and VESA (VGA, SVGA, XGA, WXGA, SXGA, UXGA) resolutions up to 1080P (60Hz & 50Hz)
SD & HD: 480I, 480p, 720p, 1080I, 1080P
VESA / DVI: From 640X480p up to 1920X1200p
Electrical Features:
100% open & short test;
Hi-pot: DC 200V 10ms
Insulation resistance: 10m ohm min
Contact resistance: 3max
Optional class:
Standard HDMI cable
High Speed HDMI cable
Standard HDMI cable with Ethernet
High Speed HDMI cable with Ethernet
|
Assignment: |
Straight Ethernet Cable, Crossover Ethernet Cable. EIA/TIA 568A 568B |
|
Shield: |
UTP, FTP,STP, |
|
Standard |
ISO/IEC 11801, TIA/EIA 568B-2, EN 50173 50288 |
|
Category: |
Cat3, Cat5e, Cat6 |
|
Conductor: |
Cu, CCA, CCS. 26AWG, 24AWG, 23AWG |
|
Jacket: |
PVC/PE/LSZH |
|
Connector: |
Plug or Boot |
|
Flammability grade |
CMX,CM,CMG,CMR,CMP |
|
Color: |
Black, White, Grey, Blue, Green, Red, Orange etc. |
|
Length: |
1.2.3 .5.7.10.15.20.30.50 meter etc. |
|
Package: |
Individual Polybag &carton or OEM requested |
