Price: | US $ 10000-20000/Piece |
---|---|
Trade Terms: | FOB,CFR,CIF |
Min Order: | 1/Piece |
Pay Type: | L/C,T/T |
MODEL | TP80 | TP120 | TP160 | TP200 | TP80 | TP120 | TP160 | TP200 | ||
MAX HYDRAULIC PRESSURE | Ton | 80 | 120 | 160 | 200 | Ib | 176000 | 264000 | 352000 | 440000 |
MAX TYRE DIMENSION | mm | 381 | 508 | 508 | 508 | inch | 15 | 20 | 20 | 20 |
TOTAL LEGHTH | mm | 1640 | 2090 | 2090 | 2090 | inch | 64.6 | 82.3 | 82.3 | 82.3 |
TOTAL MIDTH | mm | 700 | 850 | 850 | 930 | inch | 27.6 | 33.5 | 33.5 | 36.6 |
TOTAL HEIGHT | mm | 2170 | 2210 | 2210 | 2210 | inch | 85.4 | 87 | 87 | 87 |
OPERATING PRESSURE | Mpa | 21 | 25 | 33 | 33 | Mpa | 21 | 25 | 33 | 33 |
CYLINDER STROKE | mm | 400 | 400 | 400 | 400 | inch | 15.7 | 15.7 | 15.7 | 15.7 |
OIL TANK CAPACITY | L | 30 | 30 | 30 | 30 | L | 30 | 30 | 30 | 30 |
MOTOR | kw | 5.5 | 5.5 | 7.5 | 11 | hp | 7.37 | 7.37 | 7.37 | 7.37 |
WEIGHT | kg | 1100 | 1510 | 1610 | 2110 | Ib | 2420 | 3322 | 3542 | 4642 |
TOOLS | ||||||||||
TYPE | MAX TYRE DIEMENSION | CAGE (pcs) | PUSH RING (pcs) | FLANGE RING (pcs) | ||||||
Type-I | 20 | 4 | 11 | 6 | ||||||
Type-II | 25 | 5 | 12 | 7 |
Prod Model: | TP80, TP120, TP160, TP200 |
---|---|
Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Business Type: | Manufacturer |
Certificate: | ISO9001, CCC |
Delivery Time: | 7-12 Days After The Deposit or L/C |
Place Of Origine: | Shandong, China |
Type: | Tire Machinery |
Type Of General Rubber Machinery: | Forklift Tire Press Machine |
Type Of Tire Machinery: | Solid Tire Press Machinery |
Weight: | 50~300 Tons |
Voltage: | 220V |
Using Life: | ≥15 Years |
Certification: | CE, ISO |
