LED panel light/LED Panel /square LED panel/Round LED Panel /SMD3528 LED panel /high bright LED panel/LED Panels/LED Panel Lights/Dimmable LED Panels/Backlit LED Panel/High lumen and high quality/Size: 100x100/200x200/300x300/595x595/600x600/620x620/150x1200/300x1200/600x1100/600x1200
1. Super Slim Dimmable LED Panel 300x300 Description
Shenzhen Hermes Opto 's 2300LM 36W, CRI>70, PF >0.9 LED Panel 300x300 and 1170LM 18W, CRI>70, PF>0.9, LED Panel 300x300 is made up of high efficiency light guide plate + good effect diffusion plate +high quality al 6063 aluminum frame +high bright low current SMD 3528LEDs + high quality integrated LED driver. Three installing ways ( suspended, surface mounted and recessed ), three kinds of frame color ( silver /white / black ) and 5 dimming ways ( IR Dimming, RF Dimming, Manual Dimming, Dali Dimming, 0-10V Dimming, DMX Dimming ) are for customer's choice.
2. LED Panel 300x300 Advantages
A. Ultra-thin, modern, simple and elegent
B. Energy-saving, no harmful hazardous ingredients, environmental-friendly
C. Various Installation ways: Recessed or Embedded/Hanging orSuspended/Surface Mounted
D. A good replacement for traditional grille lamp.
3. Specification:
A. Power: 36W
B. Dimension: 300× 300× 11mm (12.5mm)
C. Emitting Area: 260× 260mm
D. LED: SMD3528, 372 PCS
E. Input Voltage: AC100-240V 50/60Hz
F. Luminous flux: 2200-2500Lm
G. Color Temperature: Warm White/ Pure White/ Cool White
H. CRI: >70
J. Dimmable Optional Manual rotation dimmer / IR (or RF) remote control dimmer/Dali System/0-10V dimming/TRAIC
4. LED Panel 300x300 Installations
* Recessed
* Surface Mounted
* Suspended
Delivery Time
7-10 working days for sample order, 15-20 working days for 1000PCS after payment confirmed
Payment Terms
* T/T in advance
* Western Union
* Paypal
Warranty Time
2 years since the date of purchase.
| Item | Model | Dimension | Power | LED Type | LED QTY | Lumen |
| 1 | H-S300BP18B | 300x300 295x295 | 18W | SMD3528 | 180 | 1170±10% |
| 2 | H-01530BP9B | 150X300 | 9W | SMD3528 | 90 | 540±10% |
| 3 | H-01560AP15A | 150x600 | 15W | SMD3528 | 160 | 650±10% |
| 4 | H-S300BP36B | 300x300 295x295 | 36W | SMD3528 | 372 | 2340±10% |
| 5 | H-0306BP18B | 300x600 295x595 | 24W | SMD3528 | 252 | 1560±10% |
| 6 | H-0306BP36B | 300x600 295x595 | 36W | SMD3528 | 372 | 2340±10% |
| 7 | H-S600BP36B | 600x600 595x595 | 36W | SMD3528 | 372 | 2340±10% |
| 8 | H-S600BP72B | 600x600 620x620 595x595 | 72W | SMD3528 | 744 | 4680±10% |
| 9 | H-01512BP36B | 150x1200 | 36W | SMD3528 | 372 | 2340±10% |
| 10 | H-0312BP36B | 300x1200 295x1195 | 36W | SMD3528 | 372 | 2340±10% |
| 11 | H-0312BP72B | 300x1200 295x1195 | 72W | SMD3528 | 768 | 4680±10% |
| 12 | H-0612BP72B | 600x1200 600x1100 595x1195 | 72W | SMD3528 | 768 | 4680±10% |
