Greensky Power Company Limited >> UL Small Geared Stepper Motor with Drive

UL Small Geared Stepper Motor with Drive

Name: UL Small Geared Stepper Motor with Drive
Brand: China-Manufacturer-Directory.com
SKU: 772906745
Availability: InStock
Rating: 4.5 (47 reviews)

Supplier:	Greensky Power Company Limited
Price:	US $ 1/Piece
Min Order:	100/Piece
Quantity::
Trade Terms:	FOB,CFR,CIF

Product Specifications

Prod Model:	3RK15A-H
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
All Technical Data:	Can Be Customized
Number Of Stator:	Single-Phase
Function:	Control
Certification:	CE, RoHS
Brand:	GS

Product Description

Introduction
Reversible motor has a friction brake at the back of the motor body, which is designed for applications where reversal of direction is frequently required.

Specification

Model		Output power W	Voltage V	Frequency Hz	Current A	Starting Torque mN.m	Rated Torque mN.m	Rated Speed r/min	Capacitor μF
Pinion Shaft	Round Shaft
GS3RK15GN-A	3RK15A-A	15	1ph100	50	0.4	110	125	1200	7
				60	0.56	105	105	1450
GS3RK15GN-E	3RK15A-E	15	1ph110	60	0.43	85	105	1450	6
			1ph120		0.42
GS3RK15GN-C	3RK15A-C	15	1ph220	50	0.23	110	125	1200	1.5
			1ph230
GS3RK15GN-H	3RK15A-H	15	1ph220	60	0.2	85	105	1450
			1ph230			90

Note:
Motor voltage, power and speed will be customized according to your request under the allowed circumstance of adoptable dimension.

View Of Item
About Greensky Mechanical
History: Greensky Mechanical was founded in 2012 with purchasing of a 15 year old cooperative factory in Zhejiang Province. Greensky Power brought new management concept to the new joint company and increase the quality of the motors as Greensky Power only provides best quality and best service to the society.
Introduce: Greensky Mechanical Co., ltd is a subsidiary company of Greensky Power which is producing micro AC and DC gear motor, small AC gear motor, precision planetary gearbox for servo motor, and it has capability to design and develop the micro motor, customized motor and precision gearbox, motor controller with high quality.
Philosophy:We save cost by increasing the efficiency of production and delivery. "Once and forever" is our goal to serve customers in the world. Once we do business with customer, we will do business forever.
Greensky's Advantage
On the site you can find a range of renewable products including ac/dc motor, induction motor, reversible motor, brake motor, speed control motor, ac angel motor, gear motor, planetary gearbox, worm gearbox and their relevant components.

If you have any other questions, please feel free to contact us.
