| Price: | US $ 0.1/Piece |
|---|---|
| Trade Terms: | FOB |
| Min Order: | 1/Piece |
| Pay Type: | L/C,T/T,Paypal,Western Union |
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
|---|---|
| Type: | Supercapacitor |
| Application: | General Purpose |
| Capacitance: | >100uf |
| Package Type: | Through Hole |
Part number | Rated Voltage (V) | Rated Cap. (F) | Size | Max. ESR | Maximum Endurance Current(A) | Maximum Peak Current (A) | Maximum Leakage Current (72hrs/mA) | Power Density (W/kg) | Maximum Energy (W.h) | Energy Density (Wh/kg) | |
φD×L (mm) | AC (1kHz/mΩ) | DC (mΩ) | |||||||||
ZHC2R3M106RS1020 | 2.3 | 10 | 10×20 | 100 | 180 | 0.20 | 4.11 | 0.040 | 1603 | 0.0074 | 3.3 |
ZHC2R3M226RS1030 | 2.3 | 22 | 10×30 | 80 | 150 | 0.43 | 5.88 | 0.055 | 1114 | 0.0162 | 4.3 |
ZHC2R3M226RS1B20 | 2.3 | 22 | 12.5×20 | 80 | 150 | 0.43 | 5.88 | 0.065 | 1085 | 0.0162 | 4.1 |
ZHC2R3M306RS1B25 | 2.3 | 30 | 12.5×25 | 70 | 140 | 0.59 | 6.63 | 0.080 | 889 | 0.0220 | 4.3 |
ZHC2R3M506RS1625 | 2.3 | 50 | 16×25 | 50 | 90 | 0.98 | 10.4 | 0.130 | 830 | 0.0367 | 4.3 |
ZHC2R3M127RS1840 | 2.3 | 120 | 18×40 | 30 | 50 | 2.34 | 19.7 | 0.200 | 769 | 0.0882 | 5.3 |
