Features:
1. Sine-wave output:
True sine-wave output with less than 3% THD.
2. Double Conversion Design:
Zero transfer/ complete isolation of input AC.
3. UPS Monitoring Software:
Powerful true RS232 communication via the enclosed software
To manage and safely shutdown operating systems.
4. Network RJ45/11 protection:
Complete powerful network and phone line surge protection.
5. AC Surge Suppressor:
Powerful multi-stage surge components that exceed IEEE requirements.
6. SNMP Slot Option:
7. Sleep Mode:
Worry free battery management. The unit turns itself off after ten seconds to conserve battery
Power when no power needs are detected.
8. Battery level indicators:
LED''s indicate battery levels.
9. Load Sensing:
The incorporated LED load indicators allow IT professionals to manage backup time and balance
Power loads.
10. Low Battery indicators:
The low battery level indicator will warn of eminent UPS shutdown two full minutes before unit shuts
Down.
11. Replace Battery indicators:
A preventative measure that indicates when batteries must be replaced to prevent
Server crashes.
Model
HT1KS
HT2KS
HT3KS
Rated Power
VA/W
1kVA / 0.7kW
2kVA / 1.4kW
3kVA / 2.1kW
Input
Nominal Voltage
220VAC
Voltage Range
115 ~ 300VAC
Frequency Range
46 ~ 54Hz(default), user adjustable within 40~60Hz
Power Factor
0.97
Connection
IEC320 -10A inlet
IEC320 -16A inlet
Output
Voltage
220VAC+- 2%
Frequency
46~54Hz or 50Hz+- 0.2Hz (Line mode)
50Hz+- 0.2Hz ( Battery mode)
Waveform
Sine Wave
Distortion
3%
4%
Overload Capability
108% ~ 150% for 30 sec., 150% for 300 ms
Current Crest Ratio
3: 1
Connections
IEC320 -10A *4
IEC320 -10A *6
IEC320 -10A *3 and
Terminal Block
Battery
Type
Sealed, Maintenance free, Lead-Acid
Nominal DC Voltage
36VDC
96VDC
Back-up Time
Depends on the capacity of the external battery bank
Connection
External Battery Socket
Bypass
Automatic Transfer
On overload and UPS failure
Before UPS Power-on
Default "NO", user adjustable to "YES"
Voltage Range
80 ~ 264VAC (Default), user adjustable within 80 ~ 286VAC
Transfer Time
0 ms; Less than 4 ms from inverter to bypass and vice versa
LED Indicators
Status
Load level / Battery level, Battery, Utility Power, Inverter, Bypass, Overload, Fault
Audible Alarm
Bypass, On battery mode, Battery low, Overload, Fault
Acoustic Noise
At 1 meter distance
45 dBA
50 dBA
Communications
dB-9 Port
RS-232 Serial Interface
Intelligent Slot
Options: WebPower, AS400 Card or WinPower CMC
Network Surge Protection
RJ45 I/O port available for 10 base-T network or Fax/Modem
Environmental
Operating Temperature
0 ~ 40C
Operating Humidity
20 ~ 90% non-condensing
Weight
Net (Kg)
7
13.5
14
Dimensions
W x D x H (mm)
145 x 400 x 220
192 x 460 x 348
