Product Specifications
Product Description
Characteristics:
1. Rugged Construction
Anti-1.8M drop shock. Structural stability, long-term use to meet the 24 hours required.
2. Wide Scanning Range
Whether close to 2.5mm, or as far as 600mm, can easily scan all UPC / EAN barcode.
3. Efficient, Fast, Comfortable Scanning
MJ4209 has a powerful scanning capabilities and a wider scanning range, can quickly and accurately collect data.
The plug-and-play installation design makes this product installation and use is very convenient, need hardly receive any training.
4. Supports Multiple Interfaces
Supports RS232, USB, KBW, a variety of interfaces to ensure that your existing and future terminal equipment.
User Environment
Working temperature 0° C-45° C/32° F-104° F
Storage temperature: -400° C-60° C/-40° F-140° F
Relative humidity: 5%-95%(Non-condensing)
Anti-shock design: Withstand 1.8M drops
Ambient light immunity: Immune to direct exposure of normal office and factory lighting conditions, As well as direct exposure to sunlight.
Regulatory
Electrostatic discharge: Certified to ± 15KV air discharge and ± 8KV of contact discharge
EMI/RFI: FCC Part 15 Class B, European Union EMC Directive, Taiwan EMC, CE
Laser safety: CDRH Class II, IEC Class 2
Environmental protection: Certified to RoHS directive 2002/95/EEC
Standard Configuration
Manual, Product Certification, Stand(optional), USB Cable
Warranty
The YX4209 is warranted against defects in workmanship and materials for a period of 2 years (24 months) from date of shipment, provided that the product remains unmodified and is operated under normal and proper conditions. See full warranty for details.
. Roll (Tilt): Controlled by rotating the wrist clockwise or counterclockwise
. Pitch: Controlled by dropping or raising the wrist
. Skew (Yaw): Controlled by rotating the wrist from left to right or vice versa
. Standard configuration-USB cable
Why do you choose our products?
1. Maximum Productivity at an Affordable price
Handheld laser bar code scanner form us deliverys performance features at an acceptably affordable price to made you buying decision easier than ever before. From the checkout line to the back room, our products help you make the most of your application-specific solution in a variety of ways including: Transform your Retail, Transportation&Logistics and Industrial Application.
2. Transform you Retail
Transportation&Logistics and Industrial Application Adding bar code scanning to your application-specific solution is convenient and flexible. You can configure the bar code scanner by scanning the bar code we offer to realize your wanted function in Retail, Transportation&Logistics and Industry.
Performance Characteristics
Type of illuminant
650-670nm(Visible Laser )
Scan Rate:
100 scans/second
Reading preciseness
0.10mm(4mil)
Interface:
PS2, RS232, USB and more.
Depth of field:
0-600mm(0.33mm. PCS90%)
Reading Distance:
2.5-600mm(100%UPC/EAN)
Print Contrast:
30%min
Barcode types:
1D
Scan Scope:
10mm-250mm
Bit error rate;
1/5million
Safety performance:
Accord with national level 2 laser safety standards
Physical Characteristics
Dimension:
150mm*90mm*65mm
Weight
115g
Material
ABS+PC
Color:
White/Black
User Environment
Working Temperature
0° C-45° C
Storage Temperature
-20° C-60° C
Humidity
5%-95%
Handheld &Automatic for Choice
