Product Specifications
| Prod Model: |
NU2V153M90X200GB0 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Type: |
Aluminum Electrolytic Capacitor |
| Application: |
General Purpose |
| Package Type: |
Through Hole |
| Capacitance: |
15000UF |
Product Description
1. Rated Voltage(Surage Voltage): 350V(400V)
2. Capacitance: 15000uf
3. Tolerance: ±20%(M)
4. Dissipation Factor 20C 120Hz: 0.2
5. Typ ESR 20C, 120Hz: 8mΩ
6. Rated Ripple Current 105C, 120KHz: 24.5Arms
7. Size: 90X200mm
8. Shelf Life: 1000h
9. Useful Life: 3000h
10. Temperature range: -40 to 105C
11. Packing: 12pcs/ctn
12. M5 or M6 for your choose
13. M12 Screw Bolt is available
14. Clamp include
15. Fast lead time
Suzhou UUCAP Electronic is a professional manufacturer of aluminum electrolytic capacitors which is certified to ISO 9001 and ISO 14001. All of our products are developed, designed, manufactured and inspected in accordance with ISO, UL, CE, RoHS quality standards and also passed UL, CE, ISO requirements.
Our products are distributed in mainland China, Taiwan, Hong Kong, Macau, Southeast Asia, the US, and Southwest Europe.
The Applications of Our Products:
At present, we are manufacturing over 100 items, with thousands of specifications can be applied in communication equipment, UPS & EPS power, inverter, welding machine, treadmill, AC driver, medical equipment and other automatic facilities.
Features of our aluminum electrolytic capacitors:
Load lifespan can be 3000 hours at 105 C
Big Value & high Voltage are available
Size can be selected
High ripple current
Our general products are always in stock that mini order can be shipped quickly. MOQ is 100PCS. For further information, contact us today.
