| Price: | Negotiable/Piece |
|---|---|
| Trade Terms: | FOB,CIF,EXW |
| Min Order: | 100/Piece |
| Pay Type: | L/C,T/T,Paypal,Western Union |
| Prod Model: | SZ-20022 |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Outline Dimension(Mm): | 5.08*2.75*2.58 |
| Category: | Speaker |
| Transmission Mode: | Air-conduction |
| Cone: | Paper Cone |
| Style: | Wireless |
| Transducer Principle: | Piezoelectric Earphone |
| SZ Series | SH Series | |
| Outline Dimension(mm) | 5.18*3.6 0 *3.00 | 5.08*2.75*2.58 |
| Sensitivity @1000Hz(dB) | 102.5 | 100 |
| Available Impedance Range(ohm) | 3-1000 | 3-1000 |
| THD @ Nominal Drive(%) | < 5% | < 5% |
| Maximun Output(dB) | > 130 | > 120 |
| Available Impedance | 22,60,120 | 22,60,120 |
| Typical Application |
- Receiver for hearing aid instruments ( ITE / CIC) -Tweeter/W ideband driver for headsets & headphones - Transducer for blue-tooth headsets |
- Receiver for hearing aid instruments ( IIC / CIC) -Tweeter d river for headsets & headphones - Transducer for blue-tooth headsets |
| Product Feature |
-Perfect package size for multi-driver headset applications -Outstanding efficiency -Extended bandwidth -Substantial maximum output -Magnetic-radiation shielded -Optimized mechanical shock resistance -Water resisted |
-Perfect package size for ITE,CIC,IIC applications -outstanding efficiency -Substantial maximum output -Magnetic-radiation shielded -Optimized mechanical shock resistance -Water resisted |
