Product Specifications
| Prod Model: |
BLT-60A |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Type: |
Screw |
| Performance: |
Low Noise |
| Power Source: |
AC Power |
| Configuration: |
Portable |
| Material: |
Cast Iron |
| Piston Type: |
Closed |
| Lubrication Style: |
Lubricated |
| Application: |
Back Pressure Type |
Product Description
Compair screw air compressor ; compair compressor ; screw compressor ; compressor
Features:
1. High-efficiency motor
IP55 motor (Class F insulation B rise) protects against dust and chemicals. Long-term stable operation even in harsh
environments up to 46°C (115°F).
2. State-of-the-art screw element
Patented asymmetric element profile and innovatively designed bearings offer low wear and high reliability.
Thanks to the perfect performance of the Original Atlas Copco screw element, energy consumption is reduced by 5-6%.
3. Efficient air-oil separation
Reduction of pressure drops and energy costs. Low oil consumption ensures minimal maintenance costs and long
compressor lifetime.
4. Reliable unloading/loading valve
Assures constant optimized pressure in the system resulting in high energy savings. Simple, maintenance-free set-up
with few moving parts.
5. Superior air filtration
Two-stage dust removal and filtering system with efficiency of up to 99.9% even in heavy-duty environments (particles ≥ 3 micron). Protects compressor parts and components, ensures air quality and extends the service life of the overall air system.
6. Heavy-duty oil filter
Outstanding oil purification capability ensures a clean compressor oil system. High reliability of screws, bearings and gears
in harsh environments. Long service period and easy and quick filter change reduce maintenance costs
Model |
|
BLT-60A |
Air discharge
Pressure discharge |
M3/min/bar |
8.19/7 |
7.59/8 |
6.83/10 |
5.57/13 |
No. of compression stage |
Single stage compression |
Cooling model |
|
A-Air cooling W-Water cooling |
Discharge temperature |
°C |
≤The environment temperature +15°C(Air cooling) ≤40°C(Water cooling) |
Noise Level |
dB(A) |
68±2 |
Transmission mode |
|
Direct Driven transmission |
Power supply |
V/Ph/Hz |
As your inquiry |
Motor power |
kw |
45 |
Stating model |
|
Y- Transformation Start |
External dimensions |
L |
mm |
1485 |
W |
mm |
970 |
H |
mm |
1630 |
Weight |
Kg |
860 |
Exhaust pipe diameter |
inch |
G1 1/2
|
Shanghai Zi Qi Group compressors air end has its headquarter in Germany. Its advanced technology, professional computer management system contributes to the excellent GoodAir Double Screw Air Compressor. The technology and energy consumption has achieved a new level, which can meet the European Standard. Our company always applies the advanced European design and consummate assembly technique, develop the manufacture technology and enhance the testing methods. We will provide you the best solution for air compressor system and make sure that every component has the best work condition. Therefore CoodAir Compressor applies the Original German air end and most components are world-famous brand, which makes our products well-designed and highly reliable.
We confidently believe that Shanghai Zi Qi Group is your reliable professional manufacturer for Air Compressor. We shall provide you the best Compressed Air System with our advanced technology, excellent products and services. Our products include Air & Water cooling Screw compressor, Belt & Direct Driven Screw compressor, Frequency screw compressor and Diesel Driven Portable screw compressor, Refrigeration & Adsorption air dyers, precision air filters, air tanks and screw compressor spare parts, etc. We provide high-quality Compressed Air System to make sure that the user can achieve the best productivity. The user can choose a complete Compressed Air System to meet almost every demand from our products.
