Product Specifications
| Prod Model: |
HLUX |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Function: |
with Temperature and Pressure Compensation |
| Output: |
4-20mA |
| Pressure: |
1.6/2.5/4.0MPa |
| Power Supply: |
Battery3.6V/24V DC |
| Body Material: |
Ss304 or Al Alloy |
| Kind: |
Intelligent Gas Meter |
| Application: |
Industrial |
| Diameter: |
Dn25-Dn200 |
| Precision Grade: |
1.5 |
| Starting Flow: |
2.5m3/H-3600 M3/H |
Product Description
Product Description
This air flow meter rs485 adopts the latest micro processing technology. It is featured by strong function, wide flow range, easy operation and maintenance, convenient installation. The main technical parameters reach the advanced level as the similar products both at home and abroad. It is widely used for gas metering in the fileds of petroleum, chemical engineering, electricity, metallurgy and coal.
Features
--Equipped with built-in pressure, temperature, flow rate sensor
--high security, compact structure and beautiful appearance
--Display temperature, pressure, instantaneous flow rate and the total accumulation
--Adopt the brand-new signal process amplifier and unique filter technique
--Raise the anti-interference capability of the flow meter significantly
--Function of distinctive time display and real-time data storage
--Guarantee the internal data safe and permanently no matter what happens.
--Low power consumption, enabling the long operating life only with the internal battery.
--Reliable anti-theft function with password protection, prevent the parameters from being modified.
Specification
How to select?
When you are not very clear about how to select this air flow meter rs485 model, please kindly tell us as much about the project so that we could recommend you an appropriate one, such as:
1) Where will be the meter used?
2) What's the measuring media?
3) How is the flow rate?
4) What's the pipe size?
5) How is the working condition, temperature & pressure?
6) How about the process connection and installation?
7) Other specific requirements.
All your information would be highly appreciated.
Model Selection
Model | HLUX |
|
| DN | xx |
|
| Conpensation | N | N/A |
| Y | temperature and pressure |
| Signal Output | 1 | 4-20mA two wire, pulse |
| 2 | 4-20mA three wire, pulse |
| 3 | RS485 |
| Accuracy | 1 | 1.0 |
| 2 | 1.5 |
| Pressure | 1 | 1.6MPa |
| 2 | 2.5MPa |
| 3 | 4.0MPa |
| 4 | 6.3MPa |
| Power Supply | 0 | bulit-in 3.6V battery |
| 1 | DC24V |
| Housing Material | G | stainless steel |
| L | alumnium alloy |
| Flow Range | xxx | max flow range |
