Feature1.It is light and easy to use.
2.Due to the changes of the air cap angle, the paint adhesion in the air cap is reduced.
3.Stable atomizing , more uniform coating.
4.Intensified knobs offer more stable spray air and more stable spray shape.
5.Decreased air pressure, high atomization.
6.Reduced 0.05 MPa air pressure of spray(hand), less spray spatter, lighter weight of the wrench and better particles than the original model's.
7.Well-equipped
Comparision of this gun with other guns.1.The nozzle, needle and liquid passage of it are made of 316 stainless steel
,it is very anti-corrosion, can spray a variety of corrosive paint.
2.Uniform fluid.
3.Manufactured by machine after birthed from the mold, it is of good quality.
4.Due to plating process, it has longer using life without oxidization.
ApplicationW-101-082P/W-101-102P
Automobile painting, carpentry and furniture painting, metal coating, plastic coating.
W-101-132P/W-101-152P
Carpentry and furniture painting, metal coating, spraying for medium viscosity paint.
W-101-101S/W-101-101G
Light industry.
W-101-131S/W-101-131G
W-101-132S/W-101-132G
W-1-1-134S/W-101-134G
Bicycle reparing, woodworking, furniture painting, metal coating .
W-101-151S/W-101-151G
Woodworking, furniture painting, metal coating.
W-101-152S/W-101-152G
Automobile refinishing , woodworking, and furniture painting, metal coating.
W-101-181S/W-101-181G
Woodworking, furniture painting, metal coating.
Spray distance
:200mm
Paints viscosity: 20s/NK-2
Marked:12s/NK-2.
All the paints joints: G1/4,Air joints:G1/4.
| Model | Original model | Type of feed | Fluid nozzle orifice
mm | Atomizing air pressure
MPa | Air consumption
l/min | Fluid output
ml/min | Pattern width
mm | Applied air cap | Required air compressor
kw |
| W-101-082P | W-100-082P | Pressure | 0.8 | 0.29 | | | |
E2P |
1.5 |
| W-100-102P | W-100-102P | Pressure | 1.0 | | |
| W-101-132P | W-100-132P | Pressure | 1.3 |
0.24 | | |
| W-101-152P | W-10-152P | Pressure | 1.5 | | |
| W-101-101S | W-100-101S | Suction | 1.0 | | | |
E1 |
0.4~0.45 |
| W-101-101G | W-100-101G | Gravity | 1.0 | | |
| W-1-1-131S | W-100-131S | Suction | 1.3 | | | |
K1 |
| W-101-131G | W-100-131G | Gravity | 1.3 | | |
| W-101-132S | W-100-132S | Suction | 1.3 | | | |
H2 |
0.75~1.5 |
| W-101-132G | W-100-132G | Gravity | 1.3 | | |
| W-101-134S | W-100-134S | Suction | 1.3 | 0.20 | 210 | 140 | 180 |
H4 |
| 0.24 | 250 | 145 | 200 |
| W-101-134G | W-100-134G | Gravity | 1.3 | 0.20 | 210 | 225 | 205 |
| 0.24 | 250 | 170 | 220 |
| W-101-151S | W-100-151S | Suction | 1.5 |
0.24 | 145 | 175 | 170 |
K1 |
1.5 |
| W-101-151G | W-100-151G | Gravity | 1.5 | 200 | 180 |
| W-101-152S | W-100-152S | Suction | 1.5 | 225 | 170 | 175 |
H2 | |
| W-101-152G | W-100-152G | Gravity | 1.5 | 190 | 190 |
| W-101-181S | W-100-181S | Suction | 1.8 | 170 | 210 | 170 |
N1 | |
| W-101-182G | W-100-182G | Gravity | 1.8 | 240 | 190 |
