Product Specifications
| Prod Model: |
HTQJ |
| Markets: |
North America,South America |
Product Description
1. Time range: 15, 30, 60, 120 minutes, 4, 6, 12 hours
2. Rated frequency: 50/60Hz
3. Wind up direction: Clockwise
4. Time Tolerance: +/- 6%
5. Electrical function: One minute 1800V
6. Contact pressure: 0.2N
7. Hold positon: 38°
8. Rating and Voltage: 20A, 125VAC, General use
10A, 250VAC, General use
10A, 277VAC, General use
7A, 125VAC, Tungsten
1HP, 125VAC, 1HP, 250VAC
9. Working for: Lighting, fans, A/C units, Small appliance, SPA equipment, Heat lamps, Various pool
