Product Specifications
Product Description
FEATURES:
Small in size, convenient to use
Full digital front panel calibration and parameter setting
Multiple digital filtering function
Automatic zero point tracking function
Clear automatically when turn on
With PROFIBUS interface
Can transmit data of the meter through PROFIBUS
SPECIFICATIONS:
Main Supply: 220V AC +/-10%, 50Hz; 110V AC 60Hz
Power Filter: Built-in
Operating Temperature: -10~40 Degree Centigrade
Max. Humidity: 90% R. H, cannot dew
Power Consumption: Appox. 10W
Dimensions: 98×151×49 mm
Load Cell Excitation: 12V DC Current: 350mA (Max. )
Zero Point Adjustment Range: 0.2~20mV
Input Sensitivity: 0.5μV/d
Input Range: 0.2~25mV
Conversion Mode: Sigma-Delta
A/D Conversion Speed: 200 times/Sec.
Gain Drift: 10 PPM/Degree Centigrade
Display Resolution: 1/10000
Main Display: 6 digits red nixie-tube
Secondary Display: 6 digits green nixie-tube
Status Indication: 6 green LEDs
Overload Display: OFL
Shenzhen VIDEK Technique Development Co., Ltd is a professoinal manufacturer of weighing instruments.
These are our main products:
Weighing Transmitter
Weighing Indicator
Weighing Controller
Batching Controller
Large Screen Display
We have many years experience in this industry, we can provide the best Quality, the best service and the best price. We can also provide OEM service.
So "VIDEK" is:
Your best choice!
Your best partner!
