Product Specifications
| Prod Model: |
JPCL-PAPER |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Speed: |
120m/Min |
| Laminating Resin: |
PP/LDPE/EVA/Eaa |
| Coating Thickness: |
0.012-0.05mm |
| Coating Thickness Error: |
≤±5% |
| Max Extrusion Quantity: |
200kg/H |
| Weight: |
10ton-15ton |
| Length*Width*Height: |
15*8*3m |
Product Description
Machine information
1.Main Technological Parameters
| Application of Resin | LDPE,PP,PE,EVA,EAA,EMA Coating colophony |
| Basic Material | 35-425g paper, nonwoven fabric, chemical fabric, woven fabric, aluminum foil, PVC, BOPP, BOPET, BOPA, CPP, CPE, linen |
| Max Speed | 180M/Min |
| Max Coating Width | 1300mm-2500mm |
| Coating Thickness | 0.010-0.050mm |
| Evenness of Coating | Error ±5% |
| Tension Setting Range | 10-150kg/whole range |
| Max Extrusion Amount | 245kg/hour |
| Inner Dia. Of Material Roll | 76mm |
| Total Power | 110-180KW |
| Operating Power | 70KW-85KW |
| Control System | PLC auto controlling the speed and thickness |
2.General Device list
| No. | Device | Description in detail |
| 1 | Unwinding unit | Double stations rectify unit |
| | | Bearing type scrolling unit |
| | | Magnet powder controller |
| | | Tension controller |
| | | Electric photo eyes |
| 2 | Corona treatment | Corona machine |
| 3 | Compounding unit | Compounding roller |
| | | Silica gel roller |
| | | Back press roller |
| | | Stripping silica gel roller |
| | | Swivel water connector |
| 4 | Extruder | Movable rails, buzzer, limited switches for extruder |
| | | Extruder body |
| | | Spray head |
| | | Feeding device, vacuum dryer |
| | | temperature controller for extruder |
| | | temperature controller for spray head |
| | | Gear box for extruder |
| | | Spiral screw Φ120, L:D=33:1 |
| | | Hydraulic drive screen change machine |
| 5 | Rewinding unit | Double stations rectify unit |
| | | Bearing type scrolling unit |
| | | Tension controller |
| | | Electric photo eyes |
| | | Thickness, speed, working status indicators |
| 6 | Electric cabinet | Siemens motors |
| | | Siemens frequency converter |
| | | PLC and other electric parts |
| | | Wiring, cabinet |
3.Feature
(1)Multi-functional,economical,suitable for the first time buyer.
(2)PLC Concentrated Control,Human-Machine Interface,Full Automatic Constant tension Control.
(3)High precision full closed mould head.
(4)Easy operate,low consumption,high efficiency and widely usage range.
4.Application
For producing Release Paper,Plastic Packing Paper,Non-woven Bag,Paper Cup Paper,Paper Bowl Paper,
Paper Board for food package,Duct Tape,Rice Bag,PP Woven laminate with Aluminum Foil ,PP Woven laminate with VMPET,PP Woven laminate with PP Woven,PP Woven laminate with Kraft Paper,Non-woven laminate with Aluminum Foil,Non-woven laminate with PET Film,Non-woven laminate with VMPET etc.
5.Delivery information
Packaging & Shipping
In wooden case and film cover on it by sea transportation.
Delivery term
30-60 days after receipt of 30% t/t deposit.
Delivery port
China main port (NINGBO,SHANGHAI).
6.After-sale information
Installation
Our company will send 1 technicians for installation, adjustment, training for customer, the buyer should bear all the charge such as round ticket, accommodation, food etc. the buyer also need pay salary to our engineer.
Guarantee system and maintenance
One year guarantee for the machines except the spare part, we will supply lifelong technology service to solve any problems from you. during the guarantee time, not because of man-made sabotage, we will change the parts for free,but the delivery cost need paid by buyer.
7.Company information
Company introduction
Our factory and office have strict work and rest regime,our staffs enjoy themselves ,we obey the state and local laws to protect their right.We have been embarking on extrusion coating laminating machine for 20 years.
Produce capacity
We own a team with rich experience engineer and worker,we can make 30-50 extrusion coating laminating machine every year.
Quality control
CE,ISO9001
Export markets
America,Algeria,Russia, Indonesia,Czech,Poland etc.
