| Supplier: | Shanghai Qishang International Trading Co., Ltd. |
|---|---|
| Price: | US $ 5000/Piece |
| Min Order: | 1/Piece |
| Quantity:: | |
| Trade Terms: | FOB,CFR,CIF |
|
|
| Prod Model: | SAWL |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Dimension(Long * Breadth * High): | 7*3*3.4 |
| Rated Load: | 3-8t |
| Break Out Forth: | 17ton |
| Loader Rated Power: | 162kw/2200rpm |
| Loading Hight: | 3.1m |
| Application: | Material Loading |
| Type: | Medium-sized Loader |
| Walking Mode: | Wheeled |
| Load And Unload Method: | Front Discharge |
| Certification: | ISO9001: 2000 |
| Condition: | New |
TECHNICAL PARAMETERS
Specification | Overall weight(kg) | 9500 |
L×W×H (mm) | 7050×2430×3120 | |
Rated bucket capacity(m3) | 1.6-1.8 | |
Rated load(kg) | 3000 | |
Max. dump height (mm) | 3250 | |
Bucket indicator | Yes | |
Max. breakout force(KN) | 138 | |
Engine | Model | DUTZE WP6G125E22 / CUMMINS |
Type | Direct injection, Horizontal, Water-cooled, Six stroke | |
Rated power (kw) | 92kw(125hp) | |
Rated speed(r/min) | 2400 | |
Transmission system | Model of torque converter | YJ320B |
Type | Single stage,3 elements | |
Gearbox type | Axial full power shift transmission | |
Gear shift | 4 gears ahead,2 gear astern | |
Hydraulic system | Distribution of work valve | DF25 |
Working pump | CBGj2100,CBGq2100 | |
Steering system | Type | Articulated hydraulic steering |
Max. turning angle | lift and right 36.5±1° | |
Min turning radius(mm) | 5862 | |
Brake system | Brake type | Air-break brake |
Tires | Standard tires | 17.5-25 |
Standard bucket | Width | 2300 |
I . Completely new European-style fashion design, best auxiliary part in China. Weichai engine. Hangzhou advance Gearbox and Torque Converter , Meritor drive axle Shangchai engine is optional
II . The loader adopts the single-stage-4-element hydraulic torque converter and the planetary power gearshift transmission box, which can automatically adjust the output torque. The high-speed light-load operating mode can automatically be shifted to low-speed heavy-load operating mode
III . Optimized and improved design of work unit, making the unit lifting capacity , digging force and unloading height as well as total cycle time at or better than the national figures for high-quality product
IV . The hydraulic system of the working unit adopts soft shaft operation with preset operating valve, which is featured with small pressure loss, easy and reliable operation
V . Large-vision and fully enclosed driver cab is equipped , with luxury automobile interior decoration, standard heating and ventilation equipment(air conditioner is optional)
VI . Several devices are optional according to the customer and different working condition, such as the joystick . Rops/Fops coal bucket, rock bucket and log grapple
1.Technical service
our mission:we deliver Sustainable financial returns by:Building Our Capabilities.
Focusing on our customers,Enhancing our Service Offering
2.Customer visit
After the set service period,we will measure and analyze customers'conditions and
requirements to improve
Our service quality.We also provide suggestions on how to improve their business
capabilities.
We will invite customers to witness the developing and testing process of our new
product so as to improve communications
Between SUPER-ABOVE and customer.
3.Parts support
Parts Support Department specializes in sales and support of genuine SUPER-ABOVE
parts.With an advanced ERP management system
we have integrated all OUR exclusive dealers and stores across the world.
Having a complete after-sales service system,
We are able to provide rapid parts delivery.
4.Customer training
To give a better understanding of the performance,parts,operation and maintenance
of OUR products for proper utilization
And maintainance so that they are always in optimal condition and operated at the
highest efficiency,SUPER-ABOVE has established
A professional technical center to provide regular training for customers,agencies,
and staff.
5.Service philosophy
With our 78 agencies across China,SUPER-ABOVE has established a complete after-sales
service network and owns a large number
Of after-sales service facilities.The after-sales service team will be able to reach any site
swiftly to guarantee that the customers
Get timely on-site service and will not lose profit due to lengthy delays.
