WiFi Wireless Doorbell WiFi/IP Video Door Phone Remote Unlock Picture and Video Recording Motion Sensor WiFi Waterproof Camera
Price: |
US $ 25-30/Piece |
Trade Terms: |
FOB,CIF,DAT |
Min Order: |
1/Piece |
Pay Type: |
T/T,D/P,Paypal |
WiFi Wireless Doorbell WiFi/IP Video Door Phone Remote Unlock Picture and Video Recording Motion Sensor WiFi Waterproof Camera
Specifications
1. WIFI IP Door Camera
2. Support ISO/Android
3. Talk see visitor by phone
4. Open door by phone
5. WIFI/3G/4G internet
Main Functions
1. Remote unlock
2. Picture and Video recording
3. Support IOS/Android devices
4. Wifi and Router
5. Support more than 70 languages
6. Remote monitor on smart devices
7. Remote intercom between smart phone and doorbell
8. Support multiple users
9. Check records on cloud
Hardware parameters:
Module hardware attribute | Attribute explanation |
Main core | Adapt MTK Cortex-A9 core IC ,dual core 1.3GHz |
Storage | 4GbROM(Flash)+2GbRAM(DDR) |
Network | 3G(WCDMA)/2G(GSM)+WIFI(802.11.b/g/n) |
Camera | External ,can use 30W camera , OV7725 optional,300W optional OV3640,500W optional ;these camera are 1/4CCD,angle can be wide up to 150 degree. |
Display | External,MIPI adapter ,can us 5 inches(480X854),7inches (1024X768)display |
Consumption | Stand-by current 1mA,bidding current 50mA,work current without display260mA |
Battery | External ,2000mAh minimum ,can continue work around 2 month |
External auxiliaries:
Circuit function | Function description. |
Power supply | 3.7-4.2Vpower supply |
PIR | external,support AS082+B200 moving detection |
SIM card | external,support8pin mircro SIM card( Micro SIM card 12*15mm) |
TF card | external,can expand to 32GB TF card |
Ethernet | external,supportSR9800 ic ,from RJ45 network wire adapt to USB |
MIC | external,support42db high sensitive mic |
Speaker | external,interal amplifier built in,can connect 1-3Wspeaker |
Button | On/off switch:to switch on/off machine; Reset -to reset machine; Call -to call customer mobile,or hang off communication |
Infrared night camera | Support external 850wavelength visible IR |
Indication lamp | Support external LED indication light,to show status of machine |
Standy by IO | Stand by GPIO for remote control of lock and smoke detector etc.. |
Software parameters
SOFTWARE FUNCIION | FUNCTION EXPLANATIONS |
DOORPHONE INTERCOM | Whenever there is network(WIFI/4G),customers terminal(MOBILE,TABLET) If customer usinf their mobile and customer press doorphone,,customer mobil also ringing and if customer receive the call, their last call will stop |
Remote monitor | Customer can monitor the main door situation and can listen the door situation but people at doorphone can not listen to customer's mobile tablet |
Real time security | Under the FIR moving detection system,whenever suspicious person stay in front of doorphone, our WIFI module will send alarm to customer terminal to enable their customer to monitor the situation real time. |
Remote open door | Support one remote door opening function (work under the permission from Court) |
Dialing | Support pre-selection SIM function ,if whenever customer has no network and vistor ring,can pre selection (setting) in mobile to compensate this fault; |
One key setting | Through WIFI ,customer can simplified the doorphone operation |
Video | Video format :supportH264,H263,MPEG4,VP8; Video quality (resolution):internet transmission quality 480P; Video delay : < 0.8 second (according to WIFI strength) |
Audio | Audio:supportG711,ILIBC,SPEEX etc ; Audio quality:full double ways transmission,in the hardware(software and echo suppression) and software /hardware echo depression and elimination. |
Customer terminal | Support android / ios system |
Server | Transmission:supportP2P mode; Service structure:support negative loading balance,service can establish active group |
SPECIAL FUNCTION:
FUNCTION | FUNCTIO DESCRIPTION |
Selection of doorphone | 1.Low consumption when stand by, only 1 mA standy time; 2.Video H264 calculation,low bit rate,better transmission result; 3.Audio full duplex intercom,more convenient in customer communication; 4.GSM network protection,to ensure user can receive every visitor's information; |
Can select the new doorphone | 1. Can send audio video signal to multi user mobile ,real time communication with visitor; 2.Support High Defination LCD; 3.Indoor monitor android system ,can expand and combine with other smartHome product to implement concept of internet of thing. |
Prod Model: |
HTC-W6 |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Customer Terminal: |
Support Android / Ios System |
Function: |
Remote Open Door |
Type: |
Video Doorbell |
Style: |
One-to-Many |
Talkback Type: |
Color Video |
Automation: |
Automatic |
Peephole: |
Peephole |
Wireless: |
Wireless |
Active Doorbell: |
Wireless Video Doorbell |
Wireless Video Doorbell Function: |
Visible Intertalk |
Application Scope: |
Home |
Waterproof: |
Waterproof |
Power Source: |
Plug |
Brand: |
Holdjoy |
