Product Specifications
| Prod Model: |
HLX-059 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Material: |
Low Carbon Steel Plate |
| Application: |
Filter |
| Weave Characteristic: |
Stamping |
| Surface Treatment: |
Coated |
| Hole Shape: |
Various Shapes |
Product Description
Wind dust net includes single peak wind dust net, twins peaks wind dust net and three peaks wind dust net.
Single peak wind dust net:
Forming 250mm-500mm in width
peak of high is 50mm-100mm
Plate thickness 0.5mm-1.5mm
Length: 0-4m
We can produce according to customer's requirements.
Material: Steel plate, galvanized plate, color coated sheet, stainless steel sheet.
Surface treatment: Electrostatic powder coating.
Twins peaks wind dust net:
Forming 400mm-600mm in width
peak of high is 50mm-100mm
Plate thickness 0.5mm-1.0mm.
Length: 0-10m.
We can produce according to customer's requirements.
Material: Steel plate, galvanized plate, color coated sheet, stainless steel sheet.
Surface treatment: Electrostatic powder coating.
Three peaks wind dust net:
Forming 810mm in width,
peak of high is 80mm,
Plate thickness 0.5mm-1.0mm.
Length: 0-10m.
We can produce according to customer's requirements.
Material: Steel plate, galvanized plate, color coated sheet, stainless steel sheet.
Surface treatment: Electrostatic powder coating.
Three peaks of this specification have better advantage than above two specifications, simple installation, highefficiency of construction, after install this construction, the wall have good overall performance, and can resistance strong wind. It reduces construction cost, and promotes competitiveness of construction organization in market. If the width is inappropriate, our company can according your steel structure size to make single peak, twins peaks of wind dust network, to easy combined.
Application:
1. Power plants, coal mines, coking plants, coal washing plant, and other businesses to save coal field
2. Ports, terminals and markets a variety of coal storage yard
3. Iron and steel, building materials, cement companies such as a variety of open-air yard
4. Coal storage and station of Railway and highway transportation
5. Sites, road dust.
