Wire Belts (stainless steel 316)

Name: Wire Belts (stainless steel 316)
Brand: China-Manufacturer-Directory.com
SKU: 774747045
Availability: InStock
Rating: 5 (149 reviews)

Supplier:	Yangzhou Jinrun Mesh Belt Manufacturing Co., Ltd.
Price:	US $ 10-300/Meter
Min Order:	15/Meter
Quantity::
Trade Terms:	FOB

Product Specifications

Prod Model:	AISI Type SS316
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Material:	SUS304
Hole Shape:	Round
Application:	Cages
Type:	Stainless Steel Plain Wire Mesh
Material Type:	Stainless Steel Wire
Weave Technique:	Plain Weave
Technique:	Woven
Certification:	ISO9001
Wire Mesh Width:	Customized
Nickels:	Customized

Product Description

Belt design

TL1-belt made of left and right-hand wound spirals and cross rods

For type TL1, the list dimension

1. Wire diameter of spirals

2. Diameter of cross rods

3. Spacing of cross rods

4. Width of belt

Areas of application

Wire belts are indispensable whenever air and liquids are to pass through, whenever there are extremely low or high temperatures and whenever are subjected to chemical and mechanical wear. They are used in food and paper industry, chemical, glass, canning and freezing industry, etc.

High Temperature Belt
wire mesh
stainless steel wire mesh
conveyer belt
metal mesh belt

High Temperature Belt: These belts can be used for sintering, brazing, hardening, firing, lehr,etc. It is important to select belt type and material which can endure high temperature.

Selecting belt for high temperature:

a) Select material/alloy best suited to operating temperature and atmosphere gas.

b) Select belt type capable of enduring product load.

c) Select mesh specification suited to products.

Pitch (mm)	5 6 7 7 10 13 15 15 18 20 20 20 19
Wire Diameter (mm)	1 1 1 1 1 2 2 2 3 3 3.2 3.5 5
Minimum Span (mm)	30 30 30 30 30 30 40 50 60 100 130 150 300
Overall Width (mm)	300-4200

Yangzhou Jinrun Mesh Belt Manufacturing Co., Ltd, previously named Jiangdu Second Mesh Belt Factory, is founded in 1962. For more than 50 years developing, our company is becoming the largest wire mesh belt manufacturer in China, also one of the Privately-held Technological Enterprise in Jiangsu Province. "Keeping innovating" is our company's main idea, till now, we develop for more than thousand kinds of wire mesh belts. Especially, our company innovates one kind of mesh belt, called firing furnace mesh belt, which is for solar cell industry. We offer this kind of special belt for one of the three biggest solar firing furnace companies.

Our company is majoring in four parts: Wire mesh belt, decoration wire mesh, filter screen, and plastic mesh belt. Our product has been exported to more than 20 countries, primarily the United States, Germany, Italy, France, Russia, Brazil, Japan.

"Credibility first, customer supreme" is our company's permanent commitment. We firmly believe quality is above everything. Our aim is to establish a perfect world-wide marketing system.
