Product Specifications
| Prod Model: |
CFL-200 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Brand Name: |
Huyong |
| Distinguishability: |
0.1micron |
| Testing Scope: |
More Than 0.05mm |
| Work Table Move Scope: |
50X50mm |
Product Description
Software functional brief intrudction:
1. Hole measurement: Test the hole's diameter, radius and roundness only take serval seconds.
2. Distance, combination size, length and wide testing.
3. Mark: The measured graphics can be marked.
4. Photograph: Can take pictures to any image and save.
5. Save mode: A. AUTOCAD B. WORD C. EXCEL
Specification:
1. distinguishability: 0.1μm
2. repeat pecision: ± 0.5μm
3. testing scope: ≥ 0.05mm
4. zoom mode, afocal zoom, max is 800 times.
5. One second for one test.
6. Work table move scope: 50x50mm.
7. Have halide lamp from top to bottom.
8. Power AC 220v ± 10% 50-60Hz.
Component:
1. Wire-drawing die aperture measuring instrument
2. Image system
3. Software
4. Computer
