WS-X45-SUP6L-E=
Cisco Catalyst 4500 E-Series Supervisor Engine
The Supervisor Engine 6L-E delivers 24 Gbps per slot of switching capacity when deployed with the E-Series line cards in a Cisco Catalyst 4500 E-series chassis. You can mix and match classic line cards and E-Series line cards within a Cisco Catalyst 4500 E-series chassis with no performance degradation. When you deploy the Cisco Catalyst Supervisor Engine 6L-E with classic line cards, all of the features except the 24-Gbps per-slot switching capacity are inherited.
The Cisco Catalyst Supervisor Engine 6L-E also provides flexibility and an easy migration path to 10 Gigabit Ethernet uplinks with dual-purpose X2 slots that can accommodate wire-speed 10 Gigabit Ethernet optics or Cisco TwinGig Converter Modules, enabling Gigabit Ethernet SFP optics.
PRODUCT DETAILS
Device Type Control processor
Enclosure Type Plug-in module
RAM Installed ( Max ) 512 MB ( 1 GB )
Flash Memory Installed (Max) 128 MB
Data Link Protocol Gigabit Ethernet, 10 Gigabit Ethernet
Network / Transport Protocol NTP, ICMP/IP, BOOTP, DHCP
Remote Management Protocolb SNMP 1, SNMP 2, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, TFTP, SSH, SSH-2
Performance Switching capacity: 280 Gbps
IPv4 routing: 225 Mpps
IPv6 routing: 110 Mpps
QoS hardware entries: 32000
Security services entries: 32000
Hardware forwarding entries: 57000
IPv4 routes: 57000
IPv6 routes: 30000
MAC addresses: 55000
Virtual interfaces (VLANs): 4096
Power Over Ethernet (PoE) Supported
We also have other Cisco Catalyst 4500 E-Series Supervisor Engine as following
WS-X4306-GB=
WS-X4612-SFP-E=
WS-X4624-SFP-E=
WS-X4648-RJ45V+E
WS-X4648-RJ45-E
WS-X4548-GB-RJ45
WS-X4448-GB-SFP=
Pls feel free to contact me.
Sky elaine. Hu87
|
WS-X45-SUP6L-E |
Catalyst 4500 E-Series Sup 6-E Lite, 2x10GE(X2) w/ Twin Gig |
|
WS-X45-SUP6-E |
Catalyst 4500 E-Series Sup 6-E, 2x10GE(X2) w/ Twin Gig |
|
WS-X45-SUP7L-E |
Catalyst 4500 E-Series Supervisor 7L-E, 520Gbps |
|
WS-X45-SUP7-E |
Catalyst 4500 E-Series Supervisor, 848Gbps |
|
WS-X4306-GB= |
Catalyst 4500 Gigabit Ethernet Module, 6-Ports (GBIC) |
|
WS-X4612-SFP-E= |
Catalyst 4500 E-Series 12-Port GE (SFP) |
|
WS-X4624-SFP-E= |
Catalyst 4500 E-Series 24-Port GE (SFP) |
|
WS-X4648-RJ45V+E |
Catalyst 4500 E-Series 48-Port PoE+ Ready 10/100/1000(RJ45) |
|
WS-X4648-RJ45-E |
Catalyst 4500 E-Series 48-Port 10/100/1000 (RJ45) |
|
WS-X4548-GB-RJ45 |
|
|
WS-X4448-GB-SFP= |
Catalyst 4500 48-Port 1000Base-X (SFPs Optional) |
|
C3KX-PWR-350WAC= |
Catalyst 3K-X 350W AC Power Supply |
|
C3KX-PWR-715WAC= |
Catalyst 3K-X 715W AC Power Supply |
|
PWR-C45-1300ACV |
Catalyst 4500 1300W AC Power Supply (Data and PoE) |
|
PWR-C45-1400AC |
Catalyst 4500 1400W AC Power Supply (Data Only) |
|
PWR-C45-2800ACV |
Catalyst 4500 2800W AC Power Supply (Data and PoE) |
|
C3KX-NM-1G |
Catalyst 3K-X 1G Network Module option PID |
|
C3KX-NM-10G |
Catalyst 3K-X 10G Network Module option PID |
|
C2960S-STACK = |
Catalyst 2960S Flexstack Stack Module |
|
SFP-10G-SR= |
10GBASE-SR SFP Module |
|
SFP-10G-LR= |
10GBASE-LR SFP Module |
|
GLC-T |
1000BASE-T SFP |
|
GLC-LH-SM = |
GE SFP,LC connector LX/LH transceiver |
|
GLC-SX-MMD= |
1000BASE-SX SFP transceiver module, MMF, 850nm, DOM |
|
GLC-LH-SMD |
1000BASE-LX/LH SFP transceiver module, MMF/SMF, 1310nm, DOM |
|
HWIC-1T |
1-Port Serial WAN Interface Card |
|
HWIC-2T |
2-Port Serial WAN Interface Card |
|
HWIC-2FE |
Two 10/100 routed port HWIC |
|
VWIC2-2MFT-T1/E1= |
2-Port 2nd Gen Multiflex Trunk Voice/WAN Int. Card - T1/E1 |
|
VWIC2-2MFT-G703 |
2-Port 2nd Gen Multiflex Trunk Voice/WAN Int. Card - G.703 |
|
VWIC3-2MFT-G703 |
2-Port 3rd Gen Multiflex Trunk Voice/WAN Int. Card - G.703 |
|
VWIC3-1MFT-G703 = |
1-Port 3rd Gen Multiflex Trunk Voice/WAN Int. Card - G.703 |
|
VWIC3-1MFT-T1/E1 = |
1-Port 3rd Gen Multiflex Trunk Voice/WAN Int. Card - T1/E1 |
|
VWIC3-2MFT-T1/E1 = |
2-Port 3rd Gen Multiflex Trunk Voice/WAN Int. Card - T1/E1 |
|
VWIC2-1MFT-T1/E1 |
1-Port 2nd Gen Multiflex Trunk Voice/WAN Int. Card - T1/E1 |
