X-ray Flaw Detector General Purpose
Product Specifications
| Prod Model: |
XXQ-1005 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Product Description
Application:
Our Portable X-ray Non-destructive Testing Equipments are the ideal inspection instruments used in the field of oil pipeline, chemical, aviation, astronavigation, mechanism, boiler, pressure container, shipbuilding, and national defense industries.
Features:
1. An overall self-diagnosis for software and hardware after startup can effectively detect the failure component.
2. Strong anti-interference properties make our X-ray Equipment can also work with electric generator in the wild field.
3. Quickly and exactly set exposure parameters by manual button.
4. High voltage can be started delayed to make enough time for personnel evacuate.
5. Slowly increase and decrease high voltage to protect X-ray generator
6. The ratio of working and rest is 1:1
Order Number Serials:
XXQ: Directional X-Ray Flaw Detector + Glass Tube
XXG: Directional X-Ray Flaw Detector + Ceramic Tube
XXH: Weeks to X-Ray Flaw Detector + Flat Target
XXHA: Weeks to X-Ray Flaw Detector + Cone Target
| Model | XXQ-1005
XXH-1005 | XXQ-1605
XXH-1605
XXG-1605 | XXQ-2005
XXG-2005
XXH-2005
XXHA-2005 | XXQ-2505
XXG-205
XXH-2505
XXHA-2505 | XXQ-3005
XXG-3005
XXH-3005
XXHA-3005 | XXQ-3505
XXG-3505
XXH-3505
XXHA-3505 |
| Power supply | AC220V+-10% 50Hz |
| Power (kW) | >1.0 | >1.5 | >2.5 | >2.5 | >3.0 | >3.5 |
| Tube voltage (kVp) |
| 60-160 | 80-200 | 130-250 | 150-300 | 200-350 |
| Max. Tube current (mA) | 5 | 5 | 5 | 5 | 5 | 5 |
| Focal Spot Size mm x mm | Q.G | 1.0*1.0 | 1.5*1.5 | 1.5*1.5 | 2.0*2.0 | 2.5*2.5 | 2.5*2.5 |
| H | 1.0*1.5 | 1.0*2.0 | 1.0*2.0 | 1.0*2.4 | 1.0*2.5 | 1.0*2.5 |
| HA | 1.0*2.5 | 1.0*3.5 | 1.0*3.5 | 1.0*5.0 | 1.0*6.0 | 1.0*6.0 |
| Weight kg | Tube | Q | 11 | 15 | 20 | 35 | 44 | 44 |
| G |
| 14 | 20 | 32 | 37 | 37 |
| H.HA | 11 | 15 | 20 | 35 | 44 | 44 |
| Controller | 11 |
| Radiation angle of X-ray | Q | 40º |
| G | 360º x 25º |
| H.HA | 360º x 30º |
| Max. penetration A3 steel (mm) | Q. G | 8 | 20 | 29 | 39 | 49 | 59 |
| H | 6 | 18 | 26 | 36 | 46 | 56 |
| HA |
| 15 | 24 | 34 | 40 | 50 |
| Insulation | SF6 gas |
| Environmental temperature | -25ºC ~ +40ºC |
| Relative Humidity | No more than 85% |
| Working conditions of X-Ray photography | 1. Focus to Film: 600mm
2. Exposure time: 5 min
3. Film: Tianjin Model III, intensified by double lead foil.
4. Treatment in the darkroom: Temp. 20 +/-2ºC, 5 min. blackness ≥ 1.5 |
| Safe working pressure of gas | 0.35 ~ 0.50Mpa (Operation will be prohibited in the case less than 0.35Mpa) |
