Product Specifications
| Prod Model: |
XK-SCM1 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Product Description
1. Main function:
51 microprocessor experiment and interface development application
2. Main parameters:
The power supply: DC + 12V or +5V (need short circuit J17)
Total capacity: ≤ 5W
Working environment:
Temperature -10 º C - +40 º C Relative Humidity <85% (25 ° C)
Size: 280 * 200 * 30 mm
Experiment board power supply module provides interface of GND, +5V, +2.5V and 0 ~+5V
Experiment board provides 32 I/0 interface
Experiment plate to provide four-way analog input interface (5VDC)
Experiment plate to provide four-way analog output interface (5VDC, 7VDC 2mA)
Experiment board provides four-way relay output interface(0.5A 250VAC, 1A 30VDC)
RS232 communication module
Light-emitting diode(LED) module
Independent key module
Matrix keyboard module
BCD code Nixie tube control module
Expansion IDE interface (32point I/O)
Expansion binding posts
3, Experiment project
1. Water light experiment
2. Digital display experiment
3. Independent key interface experiment
4. Matrix keyboard interface experiment
5. Driving relay output experiment
6. RS232 communication experiment
7. AT24C08 E2PROM memory experiment
8.4-channel A / D conversion experiment
9.4-way D / A conversion experiment
