Yokogawa Duplexed Field Control Unit Afv30d

Product Specifications

Prod Model:	AFV30D, AFV10D

Product Description

Yokogawa Duplexed Field Control Unit AFV30D
HARDWARE SPECIFICATIONS
For the installation specifications and the environmental conditions common to the systems, refer to "Integrated Production Control System CENTUM VP System Overview (Vnet/IP Edition)" (GS 33K01A10-50E).

Processor:VR5532 (350 MHz)
Main Memory Capacity:128 MB
Memory Protection During Power Failure
Battery
Battery Back-up for Main Memory: Max. 72 hours
Battery Recharge Time: Min. 48 hours
FCU Status Contact Output
2 terminals (NC, C)
Contact Points open during FCU failure
Contact Rating: 30 V DC, max. 0.3 A
Note: When option code /HKU is specified, a FCU fault
contact is output from the House Keeping Unit
(HKU).
Communication Interface
Vnet/IP Interface: Dual-redundant
HKU Interface (Option)
When option code /HKU is specified, a FCU
fault contact is output from the HKU. Also, the
environmental conditions of the cabinet connected via
the HK bus and optical ESB bus can be monitored and
the operating status of the HKU can be displayed on
the HIS. System alarms can also be displayed.

Power Supply
Voltage: 100-120 V AC, Frequency: 50/60 Hz
Voltage: 220-240 V AC, Frequency: 50/60 Hz
Voltage: 24 V DC
Specify with the Suffix Code.

Power Consumption
100-120 V AC: 200 VA
220-240 V AC: 230 VA
24 V DC: 5.5 A

Weight
Approx. 7 kg (AFV30S)
Approx. 8 kg (AFV30D)

Connection
Power Supply: M4 screw terminal connection
Grounding: M4 screw terminal connection
FCU Status Contact Output: M4 screw terminal
connection
Network: Connect UTP cable (CAT5e or better) to
Layer 2 switch.
Safety Standards
[CSA]
(for 100-120 V AC power supply)
[CE Marking]
(for 100-120 V AC, 220-240 V AC and 24
V DC power supply)
EMC Conformity Standards
[CE Marking]
(for 100-120 V AC, 220-240 V AC and 24
V DC power supply)
[C-Tick Marking]
(for 220-240 V AC and 24 V DC power
supply)
[KC Marking]
(for 100-120 V AC, 220-240 V AC and 24
V DC power supply)
Standards for Hazardous Location Equipment
[FM Non-Incendive]
(for 100-120 V AC, 220-240 V AC and 24
V DC power supply)
[Type n]
(for 24 V DC power supply)

MODELS AND SUFFIX CODES

Duplexed Field Control Unit
Description
Model AFV30D Duplexed Field Control Unit (for Vnet/IP and FIO, 19-inch Rack Mountable)
Suffix
Codes
-S Standard type
4 Dual-redundant Vnet/IP, dual-redundant power supply
1 Always 1
1 100 - 120 V AC power supply (*1)
2 220 - 240 V AC power supply (*1)
4 24 V DC power supply (*1)
5 Basic type with no explosion protection
6 With ISA Standard G3 option and no explosion protection
E Basic type with explosion protection
F With ISA Standard G3 option and explosion protection
1 LFS1700 Control function for field control station
(for AFV30/AFV40, Vnet/IP and FIO)
Option
Codes
/HKU With HKU interface (*2)
/ATDOC Explosion Protection Manual (*3)
Note: These products are subject to the Export Administration Regulations (EAR) by the United States Department of Commerce,
Bureau of Industry and Security (BIS). It is not possible to export or reexport these products to Iran, Cuba, North Korea,
Syria, and Sudan.
*1: To meet the safety standards and EMC standards, the unit must be installed in a keyed metallic cabinet.
*2: When used in combination with ACUKT, specify this option code "/HKU."
*3: Select the option code "/ATDOC" to follow the ATEX Directive for use in potentially explosive atmospheres.

AFV30S Field Control Unit (for FIO, 19-inch Rack Mountable)
AFV30S-S41252, AFV30S-S41252/HKU, AFV30S-S41252/ATDOC
AFV30S-S41262, AFV30S-S41262/HKU, AFV30S-S41262/ATDOC
AFV30S-S412E2, AFV30S-S412E2/HKU, AFV30S-S412E2/ATDOC
AFV30S-S412F2, AFV30S-S412F2/HKU, AFV30S-S412F2/ATDOC
AFV30S-S41152, AFV30S-S41152/HKU, AFV30S-S41152/ATDOC
AFV30S-S41162, AFV30S-S41162/HKU, AFV30S-S41162/ATDOC
AFV30S-S411E2, AFV30S-S411E2/HKU, AFV30S-S411E2/ATDOC
AFV30S-S411F2, AFV30S-S411F2/HKU, AFV30S-S411F2/ATDOC
AFV30S-S41452, AFV30S-S41452/HKU, AFV30S-S41452/ATDOC
AFV30S-S41462, AFV30S-S41462/HKU, AFV30S-S41462/ATDOC
AFV30S-S414E2, AFV30S-S414E2/HKU, AFV30S-S414E2/ATDOC
AFV30S-S414F2, AFV30S-S414F2/HKU, AFV30S-S414F2/ATDOC
AFV30S-S31252, AFV30S-S31252/HKU, AFV30S-S31252/ATDOC
AFV30S-S31262, AFV30S-S31262/HKU, AFV30S-S31262/ATDOC
AFV30S-S312E2, AFV30S-S312E2/HKU, AFV30S-S312E2/ATDOC
AFV30S-S312F2, AFV30S-S312F2/HKU, AFV30S-S312F2/ATDOC
AFV30S-S31152, AFV30S-S31152/HKU, AFV30S-S31152/ATDOC
AFV30S-S31162, AFV30S-S31162/HKU, AFV30S-S31162/ATDOC
AFV30S-S311E2, AFV30S-S311E2/HKU, AFV30S-S311E2/ATDOC
AFV30S-S311F2, AFV30S-S311F2/HKU, AFV30S-S311F2/ATDOC
AFV30S-S31452, AFV30S-S31452/HKU, AFV30S-S31452/ATDOC
AFV30S-S31462, AFV30S-S31462/HKU, AFV30S-S31462/ATDOC
AFV30S-S314E2, AFV30S-S314E2/HKU, AFV30S-S314E2/ATDOC
AFV30S-S314F2, AFV30S-S314F2/HKU, AFV30S-S314F2/ATDOC

AFV30D Duplexed Field Control Unit (for Vnet/IP and FIO, 19-inch Rack Mountable)
AFV30D-S41252, AFV30D-S41252/HKU, AFV30D-S41252/ATDOC
AFV30D-S41262, AFV30D-S41262/HKU, AFV30D-S41262/ATDOC
AFV30D-S412E2, AFV30D-S412E2/HKU, AFV30D-S412E2/ATDOC
AFV30D-S412F2, AFV30D-S412F2/HKU, AFV30D-S412F2/ATDOC
AFV30D-S41152, AFV30D-S41152/HKU, AFV30D-S41152/ATDOC
AFV30D-S41162, AFV30D-S41162/HKU, AFV30D-S41162/ATDOC
AFV30D-S411E2, AFV30D-S411E2/HKU, AFV30D-S411E2/ATDOC
AFV30D-S411F2, AFV30D-S411F2/HKU, AFV30D-S411F2/ATDOC
AFV30D-S41452, AFV30D-S41452/HKU, AFV30D-S41452/ATDOC
AFV30D-S41462, AFV30D-S41462/HKU, AFV30D-S41462/ATDOC
AFV30D-S414E2, AFV30D-S414E2/HKU, AFV30D-S414E2/ATDOC
AFV30D-S414F2, AFV30D-S414F2/HKU, AFV30D-S414F2/ATDOC

AFV40S Field Control Unit (for FIO, with Cabinet)
AFV40S-S41102,AFV40S-41102/ATDOC,AFV40S-S41102/CH,AFV40S-41102/CE
AFV40S-S41202,AFV40S-41202/ATDOC,AFV40S-S41202/CH,AFV40S-41202/CE
AFV40S-S41402,AFV40S-41402/ATDOC,AFV40S-S41402/CH,AFV40S-41402/CE

AFV40S-S42102,AFV40S-42102/ATDOC,AFV40S-S42102/CH,AFV40S-42102/CE
AFV40S-S42202,AFV40S-42202/ATDOC,AFV40S-S42202/CH,AFV40S-42202/CE
AFV40S-S42402,AFV40S-42402/ATDOC,AFV40S-S42402/CH,AFV40S-42402/CE
AFV40S-S43102,AFV40S-43102/ATDOC,AFV40S-S43102/CH,AFV40S-43102/CE
AFV40S-S43202,AFV40S-43202/ATDOC,AFV40S-S43202/CH,AFV40S-43202/CE
AFV40S-S43402,AFV40S-43402/ATDOC,AFV40S-S43402/CH,AFV40S-43402/CE
AFV40S-S44102,AFV40S-44102/ATDOC,AFV40S-S44102/CH,AFV40S-44102/CE
AFV40S-S44202,AFV40S-44202/ATDOC,AFV40S-S44202/CH,AFV40S-44202/CE
AFV40S-S44402,AFV40S-44402/ATDOC,AFV40S-S44402/CH,AFV40S-44402/CE
AFV40S-S31102,AFV40S-41102/ATDOC,AFV40S-S31102/CH,AFV40S-41102/CE
AFV40S-S31202,AFV40S-41202/ATDOC,AFV40S-S31202/CH,AFV40S-41202/CE
AFV40S-S31402,AFV40S-41402/ATDOC,AFV40S-S31402/CH,AFV40S-41402/CE
AFV40S-S32102,AFV40S-42102/ATDOC,AFV40S-S32102/CH,AFV40S-42102/CE
AFV40S-S32202,AFV40S-42202/ATDOC,AFV40S-S32202/CH,AFV40S-42202/CE
AFV40S-S32402,AFV40S-42402/ATDOC,AFV40S-S32402/CH,AFV40S-42402/CE
AFV40S-S33102,AFV40S-43102/ATDOC,AFV40S-S33102/CH,AFV40S-43102/CE
AFV40S-S33202,AFV40S-43202/ATDOC,AFV40S-S33202/CH,AFV40S-43202/CE
AFV40S-S33402,AFV40S-43402/ATDOC,AFV40S-S33402/CH,AFV40S-43402/CE
AFV40S-S34102,AFV40S-44102/ATDOC,AFV40S-S34102/CH,AFV40S-44102/CE
AFV40S-S34202,AFV40S-44202/ATDOC,AFV40S-S34202/CH,AFV40S-44202/CE
AFV40S-S34402,AFV40S-44402/ATDOC,AFV40S-S34402/CH,AFV40S-44402/CE

AFV40D Duplexed Field Control Unit (for FIO, with Cabinet)
AFV40D-S421102, AFV40D-421102/ATDOC, AFV40D-S421102/CH, AFV40D-421102/CE
AFV40D-S421202, AFV40D-421202/ATDOC, AFV40D-S421202/CH, AFV40D-421202/CE
AFV40D-S421402, AFV40D-421402/ATDOC, AFV40D-S421402/CH, AFV40D-421402/CE
AFV40D-S422102, AFV40D-422102/ATDOC, AFV40D-S422102/CH, AFV40D-422102/CE
AFV40D-S422202, AFV40D-422202/ATDOC, AFV40D-S422202/CH, AFV40D-422202/CE
AFV40D-S422402, AFV40D-422402/ATDOC, AFV40D-S422402/CH, AFV40D-422402/CE
AFV40D-S441102, AFV40D-441102/ATDOC, AFV40D-S441102/CH, AFV40D-441102/CE
AFV40D-S441202, AFV40D-441202/ATDOC, AFV40D-S441202/CH, AFV40D-441202/CE
AFV40D-S441402, AFV40D-441402/ATDOC, AFV40D-S441402/CH, AFV40D-441402/CE
AFV40D-S442102, AFV40D-442102/ATDOC, AFV40D-S442102/CH, AFV40D-442102/CE
AFV40D-S442202, AFV40D-442202/ATDOC, AFV40D-S442202/CH, AFV40D-442202/CE
AFV40D-S442402, AFV40D-442402/ATDOC, AFV40D-S442402/CH, AFV40D-442402/CE
