Product Specifications
| Prod Model: |
ZCS120 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Certification: |
CE |
Product Description
SZZCS
l Powered through the USB - no external power supply required (current consumption of less than one USB Unit Load)
l Hardware Compatible with PC or any computer or terminal with a USB interface
l Mag-Stripe reading during insertion and/or removal of card - for reliable card reading
l Reads up to three tracks of card data
l Can use standard Windows HID driver for communications; no third party device driver is required
l Programmable read direction.
l Non-volatile memory for configuration storage
l Isolated PCB - isolates electronics from debris and liquids
l Ruggedized Chassis and Bezel Material - improves temperature and impact performance
l Open Chassis Design - provides superior debris clearing capability
l Half-card Drop Out - allows half-size credit cards and coins to be cleared from insert channel.
| Reference Standards | ISO 7810 and ISO 7811 and AAMVA |
| Power Input | 5V from USB port |
| Recording Method | Two-frequency coherent phase (F2F) |
| Card Speed | 3 to 60 ips (7.62 to 152.4 cm/s) |
| Magnetic Head Durability | 500,000 insertion cycles |
| Power Consumption | Meets USB 2.0 specification for a Low-power Function |
| Storage Temperature | -40 oC to 80 oC (-40 oF to 176 oF) |
| Operating Temperature | -40 oC to 70 oC (-40 oF to 158 oF) |
| Storage Humidity | 10% to 90% noncondensing |
| Operating Humidity | 10% to 90% noncondensing |
| Operating Life | approx. 100,000 passes |
| Dimensions | 116.37mm(L)x101.6 mm(W)x76.2mm(H) |
| Weight | 200g |
Shenzhen ZCS Technology Co., Ltd.Is a professional Import and Export company that produces high quality products in the worldwide automatic identification and data collection (AIDC) and Point Of Sale markets.Our headquarters and manufactory is located in Shenzhen China.
Our products include Magnetic card reader writer, Portable Magnetic Stripe Card Readers, IC card RFID reader writer, Pinpad keyboard, and Various cards such as magnetic card, SLE card, ATMEL card etc.We also welcomes OEM/ODM businesses.With a team of top-notched technical staffs, we are able to prototype your desired specifications and eventually deliver production-quality products in a reasonably short period of time.
We strive to continue to improve our products and services.We offer most of our products with 2 years warranty and free technical support.Your choice is our glory and pride.No best, only better is our promise.Thanks for choosing us.
