SPECIFICATION
MECHANICAL
Mechanical Life: 2, 000 cycles
Operation Force: 1, 000gf max.
Stroke: 1.0 mm
Operation Temp: -20C to +85C
Storage Temperature: -40C to +85C
ELECTRICAL
Electrical Life: 2, 000 cycles
Non-switching Rating: 100mA, 50VDC
Switching Rating: 25mA, 24VDC
Contact resistance: (a) 50mO max. At initial
(b) 100mO max. After life test
Insulation Resistance: 100MO min. 500VDC
Dielectric Strength: 500VAC/ minute
Capacitance: 5pF max.
Circuit: SPST
MATERIALS
BASE & COVER: UL94V-0 PPS High-Temp. Thermoplastic, Color: Black
ACTUATOR: UL94V-0 Nylon Thermoplastic Color: White
CONTACT: Alloy Copper
TERMINAL: Brass
CONTACT PLATING: Gold plating over nickel
TERMINAL PLATING: Gold (or Tin/lead available)
TAPE PLATING: KAPTON
